GW-7472 User Manual, Version 1.0, Dec 2010 --- 51
7. Ethernet Link Object (F6
hex
)
The Ethernet Link Object contains read-only data that describes the status of the physical
Ethernet link. You can
’t directly control any attributes of this object.
Class Attributes (Instance ID = 0
hex
)
Instance Attributes (Instance ID = 1
hex
)
Common Services
7
Section 5- 4.2.2.1 of “Volume 2: EtherNet/IP Adaptation of CIP” from ODVA for more details on this attribute.
8
Section 5- 4.2.2.2 of “Volume 2: EtherNet/IP Adaptation of CIP” from ODVA for more details on this attribute.
9
Section 5- 4.2.2.3 of “Volume 2: EtherNet/IP Adaptation of CIP” from ODVA for more details on this attribute.
Attribute ID Name Data Type Data Value Access Rule
1 Revision UINT 01
dec
Get
2 Max Instance UINT 01
dec
Get
3 Number of Instances UINT 01
dec
Get
6
Max Class Attributes ID
Number
UINT 07
dec
Get
7
Max Instance Attributes
ID Number
UINT 03
dec
Get
Attribute ID Name Data Type Default Data Value Access Rule
1 Interface Speed
7
UDINT 100
dec
Get
2 Interface Flags
8
DWORD 03
dec
Get
3
Physical Address
9
ARRAYof 6
USINTs
00 0D E0 xx xx xx
hex
Get
Service Code
Implemented for
Service Name
Class Instance
0E
hex
Yes Yes Get_Attribute_Single
01
hex
Yes Yes Get_Attributes_All
