Managing the ESR901WB
Manual Documentation Number: ESR901WB-2907m pn6870-rev002
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter 6 31
3. Click the User Access link. The User Access page opens. Select
Allow command line access and/or Web Interface Access. Click
Apply. (See the online help for more information on these choices.)
4. Click the User Permissions link. The User Permissions page
appears containing a list of permissions and dropdown lists. For
each item on the list select the level of permission to be granted to
the user. (See the online help for more information on these
choices.)
Managing Serial Ports and Connections
The Management section of the Web Configuration and Management
Interface provides information about the current operational state of the
ESR901WB.
Serial Ports
The Serial Port Management page displays information on: Port number,
Description, Profile and Connections. If you click Connections the Port
Connections Management page appears displaying information on where the
port is Connected From, Connected To, the Protocol (or profile) being
used and the number of Sessions. This information can be Refreshed and, if
the Action box is selected the Disconnect button becomes available,
allowing you to disconnect.
Connections
The Connections Management page displays network connections
information including Connected From, Connected To, the Protocol in use
and the number of Sessions.
