Introduction
Manual Documentation Number: ESR901WB-2907m pn6870-rev002
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
2 Chapter 1
Features
• Wireless networking at up to 11 Mbps on the 2.4 GHz band, as
specified by the 802.11b standard
• Multi-interface switch-selectable serial port supports RS-232, RS-422
and RS-485 using a standard DB-M connector
• Supports TD, RD, TRS, CTS, DTR, DCD, DSR and GND RS-232 lines
• LAN and WAN Communications via wireless access point
• TCP or UDP Client or Server operation - configurable
• Software Support - Windows 98/ME/2000/XP/NT 4.0 or Vista
• Firmware Upload for future revisions/upgrades
• Rugged DIN rail or panel mountable IP30 enclosure
• LEDs indicate link integrity and data transfer activity
• 10/100 Mbps auto-detecting operation
• Web Configuration and Management user interface
• Email event notification
Communication Modes
ESR901WB Wireless Serial Servers allow you to connect serial devices
over a wireless network. The connection can be configured in several modes.
Direct IP
Direct IP Mode allows applications using TCP/IP or UDP/IP socket
programs to communicate with the asynchronous serial ports on the serial
server. In this mode the ESR901WB is configured as a TCP or UDP server.
The socket program running on the PC establishes a communication
connection. The data is sent directly to and from the serial port on the server.
• TCP Server Mode allows network devices to initiate a TCP connection
to the serial device connected to the serial port on the ESR901WB. This
is also referred to as reverse telnet.
• UDP Server Mode allows network devices to initiate a UDP connection
to the serial device attached to the serial port of the ESR901WB. When
using UDP protocol the ESR901WB can be configured to broadcast data
to and receive data from multiple IP addresses.
