Using the Web Configuration and Management Interface
Manual Documentation Number: ESR901WB-2907m pn6870-rev002
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter 5 17
• Network Services Settings
• Advanced Network Settings
Figure 8. Network Configuration, IP Settings Page
IP Settings
The IP Settings section allows you to select between dynamic or static IP
addressing. The ESR901WB’s default setting is Obtain an IP address
automatically using DHCP, or dynamic IP addressing.
When the ESR901WB is first connected it will try to obtain an IP address
automatically. If it fails, it will assign an IP address to itself using the Automatic
Private IP Addressing (APIPA) protocol. You can re-configure the ESR901WB
for static IP address by selecting Use the following IP address and assign the
IP address yourself.
If Use the following IP address: is selected, you are choosing static IP
addressing. When this option is selected the IP Address, Subnet Mask and
Default Gateway text boxes become available. You must determine the
appropriate parameters and enter them yourself. (If you do not know what to
enter ask your network administrator for assistance.)
To implement any changes in this section, click Apply. A page will appear
asking you to Reboot the ESR901WB so that the changes can take effect.
