Getting
Started
Manual Documentation Number: ESR901WB-2907m
pn6870-rev002
B&B Electronics Mfg Co Inc – 707 Dayton Rd - PO Box 1040 - Ottawa IL 61350 - Ph 815-433-5100 - Fax 815-433-5104 – www.bb-elec.com
B&B Electronics Ltd – Westlink Commercial Park – Oranmore, Galway, Ireland – Ph +353 91-792444 – Fax +353 91-792445 – www.bb-europe.com
Chapter
3
11
C
C
h
h
a
a
p
p
t
t
e
e
r
r
3
3
:
:
G
G
e
e
t
t
t
t
i
i
n
n
g
g
S
S
t
t
a
a
r
r
t
t
e
e
d
d
1. Check the contents of your ESR901WB package. It should
contain…
The ESR901WB module with SMA antenna
A printed version of this user manual
A printed version of the ESR901WB Quick Start Guide
CD-ROM disc with discovery software, RealPort software, this
manual and Quick Start guide
2. Set up the Hardware
Connect your PC to the network
Connect the antenna to the ESR901WB
Connect 10 VDC to 30 VDC to the power supply terminals of the
ESR901WB
Connect the ESR901WB serial port to the serial port on your serial
device
For RS-232 operation, your ESR901WB is configured as a DTE
and uses a DB-9M connector. Use a straight through RS-232
cable if your serial device is configured as a DCE. If your serial
device is configured as a DTE you will have to use a null modem
(crossover) cable.
3. Power it Up
Apply power to the ESR901WB
The yellow LED will blink while looking for a wireless network.
When a connection is established with the network the yellow LED
will remain on steadily.
The ESR901WB will automatically try to obtain an IP address
(dynamically). If it cannot find a DHCP server, it will generate an IP
address itself. It will look for a wireless network with the name
(SSID) Connect.
