26. Auto Page Rewrite Flowchart
Figure 26-1. Algorithm for Programming or Re-programming of the Entire Array Sequentially
Notes: 1. This type of algorithm is used for applications in which the entire array is programmed sequentially, filling the
array page-by-page.
2. A page can be written using either a Main Memory Page Program operation or a buffer write operation
followed by a buffer to Main Memory Page Program operation.
3. The algorithm above shows the programming of a single page. The algorithm will be repeated sequentially
for each page within the entire array.
START
Main Memory Page Program
through Buffer
(82h)
END
Provide Address
and Data
Buffer Write
(84h)
Buffer To Main
Memory Page Program
(83h)
