38 AT45DB021E [PRELIMINARY DATASHEET]
8789B–DFLASH–11/2012
15. Command Tables
Table 15-1. Read Commands
Table 15-2. Program and Erase Commands
Command Opcode
Main Memory Page Read D2h
Continuous Array Read (Low Power Mode) 01h
Continuous Array Read (Low Frequency) 03h
Continuous Array Read (High Frequency) 0Bh
Continuous Array Read (Legacy Command – Not Recommended for New Designs) E8h
Buffer Read (Low Frequency) D1h
Buffer Read (High Frequency) D4h
Command Opcode
Buffer Write 84h
Buffer to Main Memory Page Program with Built-In Erase 83h
Buffer to Main Memory Page Program without Built-In Erase 88h
Main Memory Page Program through Buffer with Built-In Erase 82h
Main Memory Byte/Page Program through Buffer without Built-In Erase 02h
Page Erase 81h
Block Erase 50h
Sector Erase 7Ch
Chip Erase C7h + 94h + 80h + 9Ah
