DS1852
14 of 25
Table 00h-FFh (Lower)
Address Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
bits<7-0> bits<7-0> bits<7-0> bits<7-0> bits<7-0> bits<7-0> bits<7-0> bits<7-0>
00h
…
…
58h
IEEE Data EEPROM
(Read Access – All, Write Access – Level 2)
60h Temp MSB Temp LSB V
cc
MSB V
cc
LSB B
in
MSB B
in
LSB P
in
MSB P
in
LSB
68h R
in
MSB R
in
LSB reserved reserved reserved reserved I/O states AD updated
70h Alarm flag3 alarm flag2 alarm flag1 alarm flag0 warn flag3 warn flag2 warn flag1 warn flag0
78h Reserved reserved reserved PWE Byte 3 PWE Byte 2 PWE Byte 1 PWE Byte 0 table select
Bytes 60h through 7Fh are RAM, see expanded table for access requirements.
Table 00h-FFh (Lower) Expanded
Byte Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
I/O states (1) D
in
reserved reserved RS
in
reserved F
in
L
in
power-on logic
AD updated
(2)
T-updated V-updated B-updated P-updated R-updated reserved reserved reserved
alarm flag3 (3) T-ad hi T-ad lo V-ad hi V-ad lo B-ad hi B-ad lo P-ad hi P-ad lo
alarm flag2 (3) R-ad hi R-ad lo reserved reserved reserved reserved reserved reserved
alarm flag1 (3) reserved reserved reserved reserved B-ft hi reserved P-ft hi reserved
alarm flag0 (3) R-ft hi reserved reserved reserved reserved reserved reserved reserved
warn flag3 (3) T-ad hi T-ad lo V-ad hi V-ad lo B-ad hi B-ad lo P-ad hi P-ad lo
warn flag2 (3) R-ad hi R-ad lo reserved reserved reserved reserved reserved reserved
warn flag1 (3) reserved reserved reserved reserved reserved reserved reserved reserved
warn flag0 (3) reserved reserved reserved reserved reserved reserved reserved reserved
(1) Read Access – All, Write Access – None
(2) Read Access – All, Write Access – All (The DS1852 will also write to this byte)
(3) Read Access – All, Write Access – Level 2 + config bit (Table 03h, E8h)
