Packaging Information
*Controlling dimension: millimeters
0.50(0.020) BSC
PIN 1 ID
0.20(.008)
0.09(.003)
0˚
7˚
0.15(0.006)
0.05(0.002) 0.75(0.030)
0.45(0.018)
1.60(0.063) MAX
7.1(0.280)
6.9(0.272)
SQ
SQ
0.27(0.011)
0.17(0.007)
9.25(.364)
8.75(.344)
48A, 48-lead, Thin (1.0 mm) Plastic Gull Wing Quad
Flat Package (TQFP)
Dimensions in Millimeters and (Inches)*
