DS2186
041295 8/11
ABSOLUTE MAXIMUM RATINGS*
Voltage on any Pin Relative to Ground 1.0V to +7V
Operating Temperature 0 ° C to 70 ° C
Storage Temperature –55 ° C to +125 ° C
Soldering Temperature 260 ° C for 10 ° C
* This is a stress rating only and functional operation of the device at these or any other conditions above
those indicated in the operation sections of this specification is not implied. Exposure to absolute maxi-
mum rating conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS (0
°
C to 70
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 1 V
IH
2.0 V
DD
+.3 V 1
Logic 0 V
IL
–0.3 +0.8 V 1
Supply V
DD
4.75 5.25 V
DC ELECTRICAL CHARACTERISTICS (0
°
C to 70
°
C; V
DD
= 5V
±
5%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Supply Current I
DD
50 mA 2,3
Supply Current I
DD
35 mA 2,4
Supply Current I
DD
20 mA 2,5
Input Leakage I
IL
–1.0 +1.0
µ
A 6
Output Current @ 0.4V I
OL
+4.0 mA 7
CAPACITANCE (t
A
= 25
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 pF
Output Capacitance C
OUT
7 pF
NOTES:
1. All inputs except MTIP and MRING.
2. V
DD
=5.25V; TCLK = LCLK = 1.544 MHz; output line transformer and load as shown in Figure 2.
3. TAIS = 1
4. 50% ones density.
5. All zeros at data inputs.
6. 0.0V < V
IN
< 5.0V.
7. Output LF (open collector).
