MAX11008
Dual RF LDMOS Bias Controller with
Nonvolatile Memory
38 ______________________________________________________________________________________
WORD ADDRESS INTERFACE (CUSTOMER) COMMAND
BIN DEC HEX MNEMONIC TABLE COMMENT
0000 0000 0 0 — —
0000 0001 1 1 — —
0000 0010 2 2 — —
0000 0011 3 3 — —
0000 0100 4 4 — —
0000 0101 5 5 — —
0000 0110 6 6 — —
0000 0111 7 7 — —
0000 1000 8 8 — —
0000 1001 9 9 — —
0000 1010 10 0A — —
0000 1011 11 0B — —
0000 1100 12 0C — —
0000 1101 13 0D — —
0000 1110 14 0E — —
0000 1111 15 0F — —
Unused. User data may
be stored here.
0001 0000 16 10 EE_TH1 7
0001 0001 17 11 EE_TL1 8
0001 0010 18 12 EE_1H1 9
0001 0011 19 13 EE_IL1 10
0001 0100 20 14 EE_TH2 7
0001 0101 21 15 EE_TL2 8
0001 0110 22 16 EE_IH2 9
0001 0111 23 17 EE_IL2 10
Nonvolatile alarm trip
points (DPRAM
locations)
0001 1000 24 18 EE_HCFIG 11
0001 1001 25 19 EE_ALMSCF 12
0001 1010 26 1A EE_SCFIG 13
0001 1011 27 1B EE_ALMHCF 14
0001 1100 28 1C EE_VSET1 15
0001 1101 29 1D EE_HIST_AP 16a, 16b
0001 1110 30 1E EE_VSET2 15
0001 1111 31 1F EE_HIST_AP 16a, 16b
Nonvolatile configuration
(DPRAM locations)
Table 4. EEPROM Address Map
