MAX11008
Dual RF LDMOS Bias Controller with
Nonvolatile Memory
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
CS_+
= +32V, AV
DD
= DV
DD
= +5V ±5%, external V
REFADC
= +2.5V, external V
REFDAC
= +2.5V, C
REF
= 0.1µF, C
GATE_
= 0.1nF,
V
SENSE
= V
CS_+
- V
CS_-
, T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at T
A
= +25°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
AV
DD
to AGND .........................................................-0.3V to +6V
DV
DD
to DGND.........................................................-0.3V to +6V
AGND to DGND.....................................................-0.3V to +0.3V
CS_+, CS_- to AGND .............................................-0.3V to +34V
CS_+ to CS_-
If CS_+ > 6V .........................................................-0.3V to +6V
If CS_+ ≤ 6V .......................................................-0.3V to V
CS_-
Analog Inputs/Outputs to AGND ..................................................
...........................-0.3V to the lower of (AV
DD
+ 0.3V) and +6V
Digital Inputs/Outputs to DGND
(except SDA/DIN and SCL/SCLK)............................................
............................-0.3V to the lower of (DV
DD
+ 0.3V) and +6V
SDA/DIN and SCL/SCLK to DGND ..........................-0.3V to +6V
Continuous Input Current (all terminals)...........................±50mA
Continuous Power Dissipation (T
A
= +70°C)
48-Pin, 7mm x 7mm, TQFN (derate 27.8mW/°C above
+70°C).....................................................................2222.2mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
HIGH-SIDE CURRENT-SENSE PGA
Common-Mode Input Voltage
Range
V
CS1+
,
V
CS2+
5
32
V
Common-Mode Rejection Ratio
CMRR
5V < V
CS_+
< 32V
110
dB
CS_+ Input Bias Current
I
CS
_+
V
SENSE
< 100mV over the common-mode
range
135
195
µA
CS_- Input Bias Current
I
CS
_-
V
SENSE
< 100mV over the common-mode
range
±1
µA
Gain = 25
0
100
Gain = 10
0
250
Full-Scale Sense Voltage Range
V
SENSE
Gain = 2
0
1250
mV
Gain = 25
75
100
Gain = 10
75
250
Minimum Sense Voltage Range
for ±0.75% V
SENSE
Accuracy
Gain = 2
75
1250
mV
Gain = 25
20
100
Gain = 10
20
250
Minimum Sense Voltage Range
for ±2.5% V
SENSE
Accuracy
Gain = 2
20
1250
mV
Total PGAOUT Voltage Error
V
SENSE
= 75mV
±0.1
±0.75
%
PGAOUT Capacitive Load
C
PGAOUT
50
pF
PGAOUT Settling Time
t
HSCS
(Note 1)
< 25
µs
Saturation Recovery Time
Settles to within ±0.5% accuracy from
V
SENSE
= 3 x full scale
< 45
µs
