SECTION

PARAMETER

EFFECTIVE

RANGE

JACK

SUPPLIES

POWER

TOUCH

X

-5 to +5V

Y

Y

-5 to +5V

Y

A

-5 to +5V

Y

GATE

+5V ON, 0V OFF

N

ENV

RATE

-5 to +5V

Y

RELEASE

+5V ON, 0V OFF

N

GATE

+5V ON, 0V OFF

N

KBD

PITCH

-5 to +5V

Y

WAVE (Note 1)

0 to +5V

Y

FILTER

CUTOFF

-5 to +5V

Y

OUT

VOL

0 to +5V

Y

PAN (Note 2)

-2.5 to +2.5V

Y

LFO

RATE

-5 to +5V

Y

SYNC

+5V ON, 0V OFF

N

MOD

MOD1

0 to +5V

Y

MOD2

-5 to +5V

Y

S&H

S&H IN

-5 to +5V

Y

GATE (Note 3)

+5V ON, 0V OFF

N

The table below shows the effective ranges of the VX-352 Inputs. All non-gate inputs supply power, allowing
you to connect either an expression pedal or a control voltage.

Note 1: The voltage range shown covers the full range of oscillator waveforms from Triangle
(0V) to Pulse (+5V). All three oscillators are effected by the WAVE input, and voltage applied to
this input adds to the oscillator dial settings.

Note 2: The voltage range shown covers the complete panning range from Full Left (-2.5V) to full
Right (+2.5V).

Note 3: All GATE inputs will accept a footswitch except for the S&H GATE. A footswitch will have
no effect on the S&H GATE input.

VX-352 CV Expander Inputs
