Voyager User’s Manual - Appendices
Page 97
Voyager User’s Manual - Appendices
SECTION PARAMETER EFFECTIVE
RANGE
TOUCH
X -5 to + 5V
Y -5 to + 5V
A -5 to + 5V
GATE +5V ON, 0V OFF
KBD
PITCH (Note 1) -0.916V to 2.667V Nominal
VEL -5 to + 5V
PRESS -5 to + 5V
GATE +5V ON, 0V OFF
WHEELS
PITCH -5 to +5V
MOD -5 to +5V
PEDALS
MOD1 (Note 2) -5 to +5V
MOD2 (Note 2) -5 to +5V
LFO
TRIANGLE +/- 2.5 V
SQUARE 0 to +3V
BUSSES
WHEEL -4 to +4V Nominal
PEDAL -4 to +4V Nominal
ENVS
FILTER 0 - 5V
VOLUME 0 - 5V
S&H
STEP -2 to +2V Nominal
SMOOTH -2 to +2V Nominal
Noise Noise +/- 1V Nominal
The table below shows the effective ranges of the VX-351 Outputs.
Note 1: The voltages shown are the Keyboard Pitch voltage range when the Voyager’s keyboard
is played. The range will be different when MIDI Note-On messages are received. The Keyboard
Pitch voltage output from the VX-351 changes by 1 volt per octave (internally adjustable).
Note 2: The MOD1 and MOD2 outputs default to +5V if nothing is connected to the MOD1 and
MOD2 inputs.
VX-351 CV Expander Outputs
