Voyager User’s Manual - MIDI
Page 77
Voyager User’s Manual - MIDI
How the Voyager handles MIDI
When you adjust any one of the Voyager’s front panel controls, MIDI Continuous Controller (CC) mes-
sages are transmitted on the MIDI Out jack. The information contained in these MIDI messages varies
according to the parameter each edit control is assigned. For example, when the FILTER CUTOFF
control is rotated, MIDI CC data corresponding to the Filter Cutoff parameter (CC#19 & CC#51) is
transmitted.
The following chart lists the MIDI CC data that is generated for each front panel control.
SECTION CONTROL FUNCTION CC VALUE/RANGE
Modulation Busses
MW SOURCE Selects the Mod Wheel bus source modulation 68 0-15 = Tri
16-31 = Square
32-47 = Osc 3
48-63 = S&H
64-79 = ON/Mod2
80-127 = Noise/PGM
MW DESTINATION Selects the Mod Wheel bus destination 69 0-15 = Pitch
16-31 = Osc 2
32-47 = Osc 3
48-63 = Filt
64-79 = Wave
80-127 = LFO Rate/PGM
MW SHAPING Selects the Mod Wheel bus modulation shaping 70 0-31 = Filt
32-63 = Velocity
64-95 = Aftertouch
96-127 = ON/PGM
MW AMOUNT Adjusts the Mod Wheel bus modulation amount 6 MSB, 38 LSB -
PEDAL SOURCE Selects the Pedal/ON bus source modulation 71 0-15 = Tri
16-31 = Square
32-47 = Osc 3
48-63 = S&H
64-79 = ON/Mod2
80-127 = Noise/PGM
PEDAL DEST. Selects the Pedal/ON bus destination 72 0-15 = Tri
16-31 = Square
32-47 = Osc 3
48-63 = S&H
64-79 = ON/Mod2
80-127 = Noise/PGM
PEDAL SHAPING Selects the Pedal/ON bus modulation shaping 73 0-31 = Filt
32-63 = Velocity
64-95 = Aftertouch
96-127 = ON/PGM
PEDAL AMOUNT Adjusts the Pedal/ON bus modulation amount 8 MSB, 40 LSB -
The Voyager’s MIDI CC data assignments
