Voyager User’s Manual - MIDI
Page 77
Voyager User’s Manual - MIDI
SECTION CONTROL FUNCTION CC VALUE/RANGE
Perf
or
mance
Controls
MOD WHEEL Modulation 1 MSB, 33 LSB -
GLIDE SWITCH Turns Glide ON/OFF 65 0-63 OFF, 64-127 ON
RELEASE SWITCH Turns Release ON/OFF 88 0-63 OFF, 64-127 ON
MOD 1 Mod 1 Input 2 MSB, 34 LSB -
MOD 2 Mod 2 Input 4 MSB, 36 LSB -
LFO
LFO RATE Adjusts the LFO frequency 3 MSB, 35 LSB 0 – 127
LFO SYNC Selects the LFO Sync mode 67 0-31 = OFF
32-63 = MIDI
64-95 = KB
96-127 = Env Gate
Oscillator
s
OSC 1 OCTAVE Sets the octave of oscillator 1 74 0-15 = 32’
16-31 = 16’
32-47 = 8’
48-63 = 4’
64-79 = 2’
80-127 = 1’
OSC 1 WAVE Sets the waveform of oscillator 1 9 MSB, 41 LSB -
OSC 2 FREQ Adjusts the frequency of oscillator 2 10 MSB, 42 LSB -
OSC 2 OCTAVE Sets the octave of oscillator 2 75 0-15 = 32’
16-31 = 16’
32-47 = 8’
48-63 = 4’
64-79 = 2’
80-127 = 1’
OSC 2 WAVE Sets the waveform of oscillator 2 11 MSB, 43 LSB -
OSC 3 FREQ Adjusts the frequency of oscillator 3 12 MSB, 45 LSB -
OSC 3 OCTAVE Sets the octave of oscillator 3 76 0-15 = 32’
16-31 = 16’
32-47 = 8’
48-63 = 4’
64-79 = 2’
80-127 = 1’
OSC 3 WAVE Sets the waveform of oscillator 3 13 MSB, 45 LSB -
1-2 SYNC Turns oscillator sync ON/OFF 77 0-63 OFF, 64-127 ON
3-1 FM Turns oscillator frequency modulation ON/OFF 78 0-63 OFF, 64-127 ON
3 KB CONT Turns keyboard control of oscillator 3 ON/OFF 79 0-63 OFF, 64-127 ON
3 FREQ Sets the HI/LO frequency range of oscillator 3 80 0-63 OFF, 64-127 ON
GLIDE RATE Adjusts the rate of glide 5 MSB, 37 LSB -
The Voyager’s MIDI CC data assignments
