Page: 1 LA-2313-00/00B
xXx BIG AIR KIT - Yamaha V-Star 950 & 1300 Models
We recommend the use of a factory service manual for all installations. Our
instructions are for use a guide only. We suggest when running the BAK with
other than stock exhaust pipes you should have your air/fuel mixture analyzed
to determine if you need a fuel injection modifier like a Dynojet, Kuryakyn,
Cobra, TFI or similar.
Revision: 3.2 - 02/16/2011
Install Time: 20 Minutes
INCLUDED IN THE KIT:
(1) Chrome or Black xXx Cover
(1) Chrome Mesh Cover
(1) Throttle Body Adapter Backplate
(1) Black Air Filter Retaining Cover
(2) 2-1/2" Aluminum Standoffs
(1) 2-3/4" Aluminum Standoff w/Turned End
(1) 1/4-20 x 1/2" Flathead Bolt
(5) 1/4-20 x 3/4" Flathead Bolts
(1) 1/4-20 x 1.00" Set Screw
(3) M5-.80 x 22mm Socket Head Cap Bolts
(1) Nylon 1/2" Nipple
(1) Air Filter
TOOLS REQUIRED:
1/8" Allen Wrench
10mm Socket & Driver
3, 4 and 5mm Allen Wrenches
Blue Loctite®
Pliers (Std or Needle Nose)
5/32" Allen Wrench
INSTRUCTIONS:
NOTE: This is a very easy install and it is not necessary to remove the fuel tank to do this installation.
1. Remove the (4) allen head screws on the outside of the stock chrome air cleaner cover.
2. Once the cover is removed, take the stock air cleaner and remove it from the filter.
3. Remove the (3) allen head bolts located at upper left and right corner and the one at the lower center of the
throttle body.
4. Remove the 10mm hex-nut located at the bottom of the black air cleaner.
5. Reach behind the front right side of the air cleaner with pliers and pinch the hose clamp on the crankcase
vent hose, so you can pull the hose from the fitting on back.
6. Remove the filter mount assembly from the bike.
7. Take the 2-3/4" aluminum spacer and put Blue Loctite® in the end that is turned down. Using a 1/8" allen
wrench thread the 1.00" set screw into that end until it seats.
8. Put Blue Loctite® on the exposed end of the set screw and thread it into the counter-bored hole directly
between the two large intake holes in the front side of the aluminum throttle body adapter backplate and
tighten this spacer firmly.
9. Put Blue Loctite® in the ends of the two 2-1/2" aluminum spacers, set them into the shallow counter-bored
holes in the same plate. Using a 5/32" allen wrench thread the two 1/4-20 x 3/4" flathead bolts into them from
the rear of the backing plate and tighten firmly.
Our install guides provide a basic outline on the proper installation of our products. Further tuning and/or
fitment may be required. LA Choppers bears no responsibility on installation costs associated with this product.
