LA-2322-00 & LA-2322-00B
xXx BIG AIR KIT (BAK) YAMAHA ROADSTAR (2008-2011)
Loctite® and torque these screws to 8 to 10 ft. lbs.
7. Using the 1/4-20x1/2" Polished Stainless Flat Head Allen Screw, attach the mesh and xXx cover and torque to
5 ft. lbs. Be sure to use Blue Loctite®.
8. Install the Neoprene hose onto the tubing protrusion on the rear of the backing plate and secure with the
supplied zip tie. Be sure not to over tighten the zip tie as you can tear the hose. There is a slight recess in the
protrusion to help secure it. Once secure, trim the excess zip tie.
9. Remove the metal hose clamp from the boot on the rear of the stock air box's rubber carb intake connector.
Slip this clamp over the BAK's Neoprene hose. Make sure you install the clamp so the screw head faces the rear
of the bike when installed.
10. Take the assembled BAK and place it into position between the cylinders. Install the crankcase vent hose on
the male hose fitting on the rear of the BAK backing plate. Route this hose so it is inconspicuous from view,
ensuring it will not get pinched or blocked in any way.
11. Align the boot from the BAK with the throttle body being sure it and the clamp slide on evenly. Then using
the M6x1.0x30mm Stainless Socket Cap Screw and short black spacer, secure the right arm of the BAK mount
arm to the engine at the upper right mount point near the top of the front push rod tube, leaving it loose at this
time.
12. Align the left arm of the BAK mount with the upper left mount point at the top of the rear push rod tube.
Use the long black spacer and the M6x1.0x45mm Stainless Socket Cap Screw to attach the left side motor
mount. Once all parts are in line, check the rubber boot for a proper seal and tighten the left and right mounts
securely. Be sure to use Blue Loctite®.
13. Tighten the hose clamp to the throttle body being sure the clamp sits evenly on the outer mouth of the body
being careful not to over tighten the clamp which may tear the tube. This clamp does not support the BAK, it is
there purely to seal against air leakage.
NOTE: We recommend you have a qualified tuning center check the air/fuel mixture of your engine in order to
determine if a fuel injection modifying devise is necessary.
Our install guides provide a basic outline on the proper installation of our products. Further tuning and/or
fitment may be required. LA Choppers bears no responsibility on installation costs associated with this product.
