Set-up, configuration
Configuration, outputs
–– Configuration PC/PLC Dependent on the basic configuration outputs
are automatically coordinated to measuring points
MST1 and MST2.
–– PC-/PLC-measured values
–– PLC 1 to
MST1
–– PLC 2 to
MST2
This coordination can be modified separately
–– PLC 3 to
--
for each output. In a list either the measuring
–– PLC 4 to
--
point numbers MST1 and MST2 or the
–– PLC 5 to
--
previously adjusted measuring point names
–– PLC 6 to
--
are available as a choice.
–– PLC 7 to
--
Example acc. to configuration measuring point
MST
name
level
MST
name
flow
–– PC/PLC relay status
off
In addition each output can be switched off
on
(– –), i.e. the switched off output does not access to
any measuring point.
–– PC/PLC Inp. status
off
on
–– Configuration VEGADIS
–– PC-/PLC-measured values
–– DIS 1 to
MST1
Configuration as abobe
–– DIS 2 to
MST2
–– DIS 3 to
--
–– DIS 4 to
--
–– DIS 5 to
--
–– DIS 6 to
--
–– DIS 7 to
--
Parameter adjustment of outputs see page 41
