H8932/H8936 INSTALLATION GUIDE
E3x Panelboard Monitoring System
The E3x meters collect a large amount of data, but only a subset of this data is presented on the H8932/H8936
Network Display, based on phase configuration and model type.
Phase Configuration:
The H8932/H8936 can be configured to display single, two, or three phased readings from the E3x meter,
based on the value selected in Modbus register 536.
Register 536 Value Display Configuration
0 or 1 = Single phase Single phase setup displays channel 1-42
2 = Two phase Two phase setup displays channel 1-21
3 = Three phase Three phase setup displays channel 1-14
Model Type:
Display* Units* Description
Model
Modbus Address
A B C
Mains
FREQ
Hz Frequency, Phase A • • 600/601
V-AN Volts Voltage, Phase A-N • • 606/607
V-BN Volts Voltage, Phase B-N • • 608/609
V-CN Volts Voltage, Phase C-N • • 610/611
V-AB Volts Voltage, Phase A-B • • 612/613
V-BC Volts Voltage, Phase B-C • • 614/615
V-AC Volts Voltage, Phase A-C • • 616/617
AUX KWH kWh Aux. Total Energy • • 618/619
AUX KW kW Aux. Total Real Power, Phases A, B, C • • 620/621
AUX PF --- Aux. Total Power Factor • • 622/623
AUX AMPS Amps Aux. Average Current, Phases A, B, C • • • 624/625
Branch Circuits (1 to 42), Single Phase (xx = channel number, 1 through 42)
Mxx KWH
kWh Energy • 2000 to 2083
Mxx KW kW Real Power • 2084 to 2167
Mxx PF --- Power Factor • 2168 to 2251
Mxx AMPS Amps Current • • • 2252 to 2335
Branch Circuits (1 to 42), Two Phase (xx = channel number, 1 through 42)
Mxx KWH
kWh Energy • 5000 to 5041
Mxx KW kW Real Power • 5042 to 5083
Mxx PF --- Power Factor • 5084 to 5125
Mxx AMPS Amps Current • • • 5126 to 5167
Branch Circuits (1 to 42), Three Phase (xx = channel number, 1 through 42)
Mxx KWH
kWh Energy • 8000 to 8027
Mxx KW kW Real Power • 8028 to 8055
Mxx PF --- Power Factor • 8056 to 8083
Mxx AMPS Amps Current • • • 8084 to 8111
* The prefix (k) changes to M or G for very large readings.
