H8932/H8936
INSTALLATION GUIDE
E50Cx Power and Energy Meter
Display*
Units*
Description
Modbus Address
KWH
kWh
Energy Consumption
259/260
KW
kW
Real Power
261/262
KVAR
kVAR
Reactive Power
263/264
KVA
kVA
Apparent Power
265/266
PF
---
Power Factor
267/268
V-LL
Volts
Average Voltage, L-L
269/270
V-LN
Volts
Average Voltage, L-N
271/272
AMPS
Amps
Average Current
273/274
KW-A
kW
Real Power, Phase A
275/276
KW-B
kW
Real Power, Phase B
277/278
KW-C
kW
Real Power, Phase C
279/280
PF-A
---
Power Factor, Phase A
281/282
PF-B
---
Power Factor, Phase B
283/284
PF-C
---
Power Factor, Phase C
285/286
V-AB
Volts
Voltage, Phase A-B
287/288
V-BC
Volts
Voltage, Phase B-C
289/290
V-AC
Volts
Voltage, Phase A-C
291/292
V-AN
Volts
Voltage, Phase A-N
293/294
V-BN
Volts
Voltage, Phase B-N
295/296
V-CN
Volts
Voltage, Phase C-N
297/298
AMPA
Amps
Instantaneous Current, Phase A
299/300
AMPB
Amps
Instantaneous Current, Phase B
301/302
AMPC
Amps
Instantaneous Current, Phase C
303/304
FREQ
Hz
Frequency, derived from Phase A
307/308
KVAH
kVAh
Apparent Energy Consumption
309/310
KVRH
kVARh
Reactive Energy Consumption
311/312
KVAA
kVA
Apparent Power, Phase A
313/314
KVAB
kVA
Apparent Power, Phase B
315/316
KVAC
kVA
Apparent Power, Phase C
317/318
KVRA
kVAR
Reactive Power, Phase A
319/320
KVRB
kVAR
Reactive Power, Phase B
321/322
KVRC
kVAR
Reactive Power, Phase C
323/324
PDKW
kW
Total Real Power Present Demand
325/326
PDKR
kW
Total Reactive Power Present Demand
327/328
PDKA
kW
Total Apparent Power Present Demand
329/330
MDKW
kW
Total Real Power Max. Demand
331/332
MDKR
kW
Total Reactive Max. Present Demand
333/334
MDKA
kW
Total Apparent Max. Present Demand
335/336
E51Cx Power and Energy Meter
Display*
Units*
Description
Modbus Address
KWH
kWh
Accumulated Real Energy: Net (Import -
Export)
257/258
KVAH
kVAh
Apparent Energy: Net (Import - Export)
271/272
KW
kW
Total Net Instantaneous Real Power
277/278
KVAR
kVAR
Total Net Instantaneous Reactive Power
279/280
KVA
kVA
Total Net Instantaneous Apparent Power
281/282
PF
---
Power Factor
283/284
V-LL
Volts
Average Voltage, L-L
285/286
V-LN
Volts
Average Voltage, L-N
287/288
AMPS
Amps
Average Current
289/290
FREQ
Hz
Frequency
290/291
PUL 1
kW
Pulse Counter 1 (Import Real Energy)
313/314
PUL 2
kW
Pulse Counter 2 (Export Reactive Energy)
315/316
KW-A
kW
Real Power, Phase A
365/366
KW-B
kW
Real Power, Phase B
367/368
KW-C
kW
Real Power, Phase C
369/370
KVRA
kVAR
Reactive Power, Phase A
371/372
KVRB
kVAR
Reactive Power, Phase B
373/374
KVRC
kVAR
Reactive Power, Phase C
375/376
KVAA
kVA
Apparent Power, Phase A
377/378
KVAB
kVA
Apparent Power, Phase B
379/380
KVAC
kVA
Apparent Power, Phase C
381/382
PF-A
---
Power Factor, Phase A
383/384
PF-B
---
Power Factor, Phase B
385/386
PF-C
---
Power Factor, Phase C
387/388
V-AB
Volts
Voltage, Phase A-B
389/390
V-BC
Volts
Voltage, Phase B-C
391/392
V-AC
Volts
Voltage, Phase A-C
393/394
V-AN
Volts
Voltage, Phase A-N
395/396
V-BN
Volts
Voltage, Phase B-N
397/398
V-CN
Volts
Voltage, Phase C-N
399/400
AMPA
Amps
Instantaneous Current, Phase A
401/402
AMPB
Amps
Instantaneous Current, Phase B
403/404
AMPC
Amps
Instantaneous Current, Phase C
405/406
PDKW
kW
Total Real Power Present Demand
293/294
PDKR
kW
Total Reactive Power Present Demand
295/296
PDKA
kW
Total Apparent Power Present Demand
297/298
MDWI
kW
Total Real Power Max. Demand
299/300
MDRI
kW
Total Reactive Power Max. Demand
301/302
MDAI
kW
Total Apparent Power Max. Demand
303/304
MDWE
kW
Total Real Power Max. Demand
305/306
MDRE
kW
Total Reactive Power Max. Demand
307/308
MDAE
kW
Total Apparent Power Max. Demand
309/310
* The prefix (k) changes to M or G for very large readings.
