Installation Guide
Power Monitoring
H81xx
TM
Optional Comm Board (sold separately)
Model Description
H8163-CB Modbus® Communications Board for H81xx Series
H8186-CB BACnet® Communications Board for H81xx Series
H8126-CB Metasys® N2 Communications Board for H81xx Series (consult factory if ordering this item)
Optional Accessory
Model Description
AH06 Mounting Bracket Kit (fits the Small, Medium, and Large CTs only)
Product Identification
(cont.)
Specifications
INPUTS
H8150 90 to 132VAC line-to-neutral
H8163, H8167 90 to 300VAC line-to-neutral
Frequency 50/60 Hz
ACCURACY
System Accuracy ±1% of reading from 2% to 100% of the CT current rating *
Sample Rate 1280 Hz
OUTPUTS
All Models 1.2” x 3.8” (31 mm x 97 mm) viewing area, 160 segments, backlit LCD
H8163 and H8167
PULSE OUTPUT
PULSE RATE
PULSE WIDTH
PHASE LOSS ALARM OUTPUT
N.O., Opto-FET, 100mA@24VAC/DC
0.10, 0.25, 0.50, 1.00 kWh per pulse (jumper selectable)
200msec closed
H8163: N.O. (opens on alarm, remains open while alarm persists);
H8167: N.C. (closes on alarm, remains closed while alarm persists);
Both H8163 and H8167: Opto-Fet, 100mA@24VAC/DC;
Fixed threshold 25% below any other phase
MECHANICAL
Protection Class NEMA 1
Insulation Class 600 VAC **
OPERATING CONDITIONS
Operating Temperature Range 0° to 50°C (32° to 122°F)
Storage Temperature Range -40°C to 70°C (-40° to 158°F)
Humidity Range 0-95% RH, non-condensing
Altitude of Operation 0 to 2000 m
ELECTRICAL SERVICES
H8150 120/240 VAC with neutral, 208Y/120 VAC line-to-neutral
H8163, H8167 Any Wye service in which the phase L-N voltage is ≤300VAC and the phase-to-
phase voltage is ≤480 VAC nom. with neutral
COMPLIANCE INFORMATION
Agency Approvals UL 61010
Installation Category Cat III, pollution degree 2
* Meters and current transformers are calibrated as a set. To achieve this accuracy, match the serial numbers on the current
transformers and the meter at the time of installation (does not apply to 100 A CTs).
** Do not apply 600V class current transformers to circuits having a phase-to-phase voltage greater than 600V without adequate
additional insulation between primary conductor and current transformers.
