Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 93)

X510-9
93
Variable Parts Listing
Kits & Parts - Use With All Applications
Bills of Material
Description & Item Number
(Refer to "Exploded View" at
the front of this section)
603651 603652 603653 603916 603918
603695
603696
603841
1 KIT – Inner Pinion Bearing 3 706060X 706060X 706060X 706060X 706060X
2 PKG – Diff & Pinion Bearing Shim - 706213X 706077X 706213X 706213X 706213X
3 PKG – Pinion Bearing Shim - 706357X 706357X 706357X 706357X 706357X
4 Baffle – Pinion Bearing 5 34849 34849 34849 34849 34849
5 Flat Spacer – Outer Pinion Bearing 6 — 46176 — — —
6 End Yoke Assembly (inc 11) 12 — (9) — (9) — (9) — (9) — (9)
7 Washer – Pinion Nut 13 30275 30275 30275 30275 30275
8 KIT – Carrier Cover - 706689X 706689X 706689X 706689X 706689X
9 Carrier Cover 15 33865 33865 33865 33865 33865
10 KIT – Differential Bearing 21 706047X 706070X 706047X 706070X 706047X
11 PKG – Diff Bearing Shim (inc 18) 22 708012 708012 708012 708012 708012
12 Bolt – Drive Gear (qty 12) 24 30266 30266 30266 30266 30266
13 Gear – Differential (std) 26 35079 35079 35079 35079 35079
14 Gear – Differential (p/l) 46 35294 35294 35294 35294 35294
603955 603995 603998 605158 605192
603997
1 KIT – Inner Pinion Bearing 3 706060X 706060X 706060X 706861X 706861X
2 PKG – Diff & Pinion Bearing Shim - 706213X 706213X 706077X 706863X 706863X
3 PKG – Pinion Bearing Shim - 706357X 706357X 706357X 706862X 706862X
4 Baffle – Pinion Bearing Bearing 5 34849 34849 34849 — —
5 Flat Spacer – Outer Pinion 6 — — — 46176 46176
6 End Yoke Assembly (inc 11) 12 — (9) — (9) — (9) — (9) 2-4-8391-1X
7 Washer – Pinion Nut 13 30275 30275 30275 30275 30275
8 KIT – Carrier Cover - 706689X 706689X 706689X 707181X 706980X
9 Carrier Cover 15 33865 33865 33865 42815-2 38454
10 KIT – Differential Bearing 21 706047X 706047X 706070X 706047X 706047X
11 PKG – Diff Bearing Shim (inc 18) 22 708012 708012 706373X 708012 708012
12 Bolt – Drive Gear (qty 12) 24 40638 30266 30266 40638 30266
13 Gear – Differential (std) 26 35079 35079 35079 35079 35079
14 Gear – Differential (p/l) 46 35294 35294 35294 35294 35294
605214 605235 605269 605311 605373
605215 605270 605312
605313
1 KIT – Inner Pinion Bearing 3 706861X 706861X 706861X 706861X 706861X
2 PKG – Diff & Pinion Bearing Shim - 706863X 706863X 706863X 706863X 706863X
3 PKG – Pinion Bearing Shim - 706862X 706862X 706862X 706862X 706862X
4 Baffle – Pinion Bearing 5 — — — — —
5 Flat Spacer – Outer Pinion Bearing 6 46176 46176 46176 46176 46176
6 End Yoke Assembly (inc 11) 12 — (9) 3-4-5711-1X — (9) 3-4-5711-1X — (9)
7 Washer – Pinion Nut 13 30275 30275 30275 30275 30275
8 KIT – Carrier Cover - 706689X 707181X 706689X 707181X 707181X
9 Carrier Cover 15 33865 42815-2 33865 42815-2 42815-2
10 KIT – Differential Bearing 21 706047X 706047X 706047X 706047X 706047X
11 PKG – Diff Bearing Shim (inc 18) 22 708012 708012 708012 708012 708012
12 Bolt – Drive Gear (qty 12) 24 30266 40638 30266 40638 40638
13 Gear – Differential (std) 26 35079 35079 35079 35079 35079
14 Gear – Differential (p/l) 46 35294 35294 35294 35294 35294
(See next page for additional bills of material)
Dodge Model 70 /267 Rear Axles
(9) Must identify yoke series used in vehicle; Service 7260 Series with 1310 Series using 2-4-8391X, 5-353X and 2-70-18X. Service 7290
Series with 2-4-7681-1X. Service 1410 Series with 3-4-5711-1X. Contact vehicle manufacturer for 5380 Series.
