X510-9
230
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
605807 605831 605834 605924 605925
1 KIT – Inner Pinion Bearing 3 707065X 707065X 707065X 707447X 707447X
2 PKG – Pinion Bearing Shim - 707066X 707066X 707066X 707480X 707480X
3 PKG – Diff & Pinion Bearing Shim - 707365X 707365X 707365X 707481X 707481X
4 End Yoke Assembly (inc 10) 9 75725X 3-4-11081-1X 75725X 3-4-11081-1X 3-4-11281-1X
5 Slinger – End Yoke 10 42432 42432 42432 231872 231872
6 KIT – Carrier Cover - 707231X 707231X 707231X 707479X 707478X
7 Carrier Cover 13 42434 42434 42434 47717-1 47843
8 Plug – Carrier Cover 14 38637 38637 38637 38637 38637
9 Bolt – Carrier Cover (qty 10) 15 34822 34822 34822 34822 47508
10 KIT – Differential Outboard Spacer 20 701133X (9) 701133X (9) 701133X (9) 701133X (9) 701133X (9)
11 PKG – Differential Bearing Shim 21 707364X 707364X 707364X 707364X 707364X
12 Gear – Differential (std) 26 42411 43652 42411 42411 43652
13 Oil Seal (Inner Wheel) 30 47507 44303 47507 47507 47860
14 Bearing Cone – Inner Wheel 31 565906 565962 565906 565906 566071
15 Bearing Cone – Outer Wheel 33 565911 566057 565911 565911 550348
16 Retainer – Wheel Bearing (RH) 34 43075 46471 43075 43075 47858
17 Retainer – Wheel Bearing (LH) - 43075 46471 43075 43075 47858
18 Gasket 35 39697 42445 39697 — —
19 Screw & Lockwasher Assembly 37 45720 45816 45720 45816 45816
20 Shaft – Differential (t/l) 40 — — — 47802 —
21 Gear – Differential (t/l) 41 — — — 47796 —
22 Thrustwasher – Pinion (t/l) 42 — — — 47800 —
23 Pinion – Differential (t/l) 43 — — — 47798 —
24 KIT – Disc & Plate (t/l) - — — — 702009 —
25 Bolt – Differential Case (t/l) 47 — — — 41610-1 —
26 Retainer Ring / O-Ring 48 — — — 47893 47857
27 Spindle Nut 49 — — — — —
28 Lockwasher – Spindle Nut 50 — — — — —
(See next page for additional bills of material)
Ford Model 80 /286 Rear Axles
(9) 701133X & 707069X contain bearing preload spacers which can be purchased separately. See Differential Bearing Adjustment Shim
Table, at the back of the Ford section of this catalog, for thickness applications. The bearing cone spacer (44849) can be purchased
separately in kit 701152X.
