Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 169)

(1) See "Bill of Material Table" below
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 706015X KIT – Inner Pinion Bearing
4 — Inner Pinion Bearing Shims
(see shim packages)
5 32349 Baffle – Pinion Bearing
706386X PKG – Diff & Pinion Bearing Shim
(inc items 4, 6, 11, 12, 15, 21)
6 — Outer Pinion Bearing Shims
(see shim packages)
706360X PKG – Diff & Pinion Bearing Shim
(inc items 4, 6, 11, 12, 15)
7 706014X KIT – Outer Pinion Bearing
8 41012 Slinger – Pinion Bearing Outer
9 41455 Seal – Pinion Oil
10 2-4-5251X End Yoke Assembly (inc 10A)
10A 41498 Slinger – End Yoke
11 30186 Washer – Pinion Nut
12 30185 Pinion Nut
13 — (3) Companion Flange Assembly
707076X KIT – Carrier Cover
(inc items 14, 16, 17)
14 41939 Carrier Cover
15 34684 Gasket – Carrier Cover
16 41356 Plug – Carrier Cover
17 34279 Bolt – Carrier Cover (qty 10)
18 — (3) Differential Bearing Cap
19 40284-1 Bolt – Differential Bearing Cap
20 706016X KIT – Differential Bearing
21 706086X PKG – Diff Bearing Shim (inc 15)
22 — (4) Case – Differential
23 30187 Bolt – Drive Gear (qty 10)
24 32926 Pinion – Differential
25 33213 Gear – Differential
26 34096 Thrustwasher – Diff Pinion
27 34095 Thrustwasher – Diff Gear
28 41648 Shaft – Differential
29 13449 Lock – Differential Shaft
30 34616-1 Bolt – Brake Mounting
31 35704 Nut – Brake Mounting
706851X KIT – Unit Bearing and Seal
(inc items 32, 33, 34, 35)
32 36121 Retainer Ring – Wheel Bearing
33 565909 Wheel Bearing Assembly
34 35938 Seal – Outboard Shaft
35 41647 Retainer – Oil Seal
36 — (1) Axle Shaft
37 38638 Bolt – Axle Shaft
169
X510-9
Parts Listing
Ford Model 30 /181 Rear Axles
Bill of Material Table
1986-88 1A Aerostar Van
605273-1 Standard 3.73 706000-20X 72720X 706008X 707041X 72499-1X 72499-2X
605273-2 Standard 3.73 706000-3X 72720X 706008X 707041X 72499-1X 72499-2X
605273-3 Standard 3.45 706000-21X 72721X 706007X 707041X 72499-1X 72499-2X
1989 1/2 1A Aerostar Van
605434-1 Standard 3.73 706000-20X 72720X 706008X 707041X 72499-1X 72499-2X
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy. Kit (8) Case Kit Inner Parts Kit
Right Hand
Shaft Assy. Left Hand
Shaft Assy.
