259
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" below
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
X510-9
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
GM Model 60 /248 Rear Axles
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 706046X KIT – Inner Pinion Bearing
706375X PKG – Diff & Pinion Bearing Shim
(inc items 4, 6, 12, 13, 17, 21)
706359X PKG – Pinion Bearing Shim
(inc items 4, 6, 12, 13, 17)
4 — Inner Pinion Bearing Shims
(see shim packages)
5 30982 Baffle – Pinion Bearing
6 — Outer Pinion Bearing Shims
(see shim packages)
7 706045X KIT – Outer Pinion Bearing
8 42737 Thrustwasher
9 42449 Seal – Pinion Oil
10 3-4-5731-1X End Yoke Assembly (inc 11)
Bearing strap kit used w/end yoke
11 232752 Slinger – End Yoke
12 30275 Washer – Pinion Nut
13 30271 Pinion Nut
— (2) KIT – Carrier Cover
(inc items 14, 15, 16)
14 — (2) Carrier Cover
15 34822 Bolt – Carrier Cover
16 — (2) Plug – Carrier Cover
17 34687 Gasket
18 — (3) Differential Bearing Cap
19 48632-1 Bolt – Differential Bearing Cap
20 706047X KIT – Differential Bearing
21 706378X PKG – Diff Bearing Shim (inc 17)
22 — (4) Case – Differential (std)
23 40638 Bolt – Drive Gear (qty 12)
24 34367 Pinion – Differential (std)
25 35625 Gear – Differential (std)
26 34730 Thrustwasher – Diff Pinion (std)
27 34729 Thrustwasher – Diff Gear (std)
28 30263 Shaft – Differential (std)
29 44810 Lock – Differential Shaft
30 — (3) Bolt – Brake Mounting
31 — (3) Nut – Brake Mounting
32 — (3) Hub Seal
33 706179X KIT – Inner Wheel Bearing
34 706074X KIT – Outer Wheel Bearing
35 — (3) Wheel Hub
36 — (2) Thrustwasher – Wheel Bearing
37 — (2) Spindle Nut
38 — (2) Lockwasher – Wheel Bearing
39 — (3) Spindle Nut
40 — (3) Key – Square
41 — (3) Snap Ring
42 36554 Gasket
43 — (1) Axle Shaft
44 37871 Bolt – Axle Shaft
603702 605000 605132 605201
603884 605001 605133 605268
605200 605403
605405
605495
605496
1 KIT – Carrier Cover - 706128X 707108X 707233X 707108X
2 Carrier Cover 14 34675 42799-2 43600-1 42799-2
3 Plug – Carrier Cover 16 36472 43180 43180 43180
4 Thrustwasher – Wheel Bearing 36 33734 — — —
5 Spindle Nut 37 33732 — — —
6 Lockwasher – Wheel Bearing 38 33733 — — —
Kits & Parts - Use With All Applications
Description & Item Number Bills of Material
(Refer to "Exploded View"
on previous page)
Variable Parts Listing
