X510-9
3
Dodge Model 35 /194 IFS Front Axles
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 701130X PKG – Inner Pinion Shim
4 707162X KIT – Inner Pinion Bearing
5 42102 Collapsible Spacer
6 706894X KIT – Outer Pinion Bearing
7 42778 Slinger – Outer Pinion Bearing
8 48009 Seal – Pinion Oil
9 48008 Seal – End Yoke
10 2-4-8131-1 End Yoke
11 44189 Pinion Nut
707438X KIT – Carrier Cover
12 — (4) Carrier Cover
13 41356 Plug – Carrier Cover
14 40286-5 Bolt – Carrier Cover (qty 10)
15 38615 RTV Silicone Sealant
16 — (3) Differential Bearing Cap
17 40284-1 Bolt – Differential Bearing Cap
18 706016X KIT – Differential Bearing
19 701004X PKG – Differential Bearing Shim
20 — (1) Case – Differential
21 41221 Bolt – Drive Gear (qty 10)
22 42570 Snap Ring
23 46504 Pinion – Differential
24 47559 Gear – Differential
25 34096 Thrustwasher – Differential Pinion
26 34095 Thrustwasher – Differential Gear
27 41648 Shaft – Differential Pinion
28 13449 Lock – Differential Shaft
29 565977 Bearing
30 46485 Oil Seal
31 47067 Shaft – Axle (LH)
32 47065 Shaft – Axle (RH)
33 41962 Vent – Axle Shaft (RH)
(1) See "Bill of Material Table" Below
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
Bill of Material Table
1997-99 DAKOTA
610576-1 Standard 3.21 75812-5X 75935X 47071 707436X — —
610576-2 Standard 3.55 74346-5X 75934X 47069 707436X — —
610576-3 Standard 3.92 75813-5X 75934X 47069 707436X — —
1997-99 DURANGO
610576-4 Standard 3.21 75812-5X 75935X 47071 707436X — —
610576-5 Standard 3.55 74346-5X 75934X 47069 707436X — —
610576-6 Standard 3.92 75813-5X 75934X 47069 707436X — —
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy. Kit (8) Case Kit Inner Parts Kit
Right Hand
Shaft Assy. Left Hand
Shaft Assy.
