Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 302)

X510-9
302
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
610668 610669 610670 610671 610672
1 Seal – Pinion Oil 10 — — — 44895 44895
2 End Yoke or Assembly (inc 12) 11 — — — 2-4-6561-1 2-4-6561-1
3 Slinger – End Yoke 12 — — — — —
4 KIT – Carrier Cover - — — — 707180X 707180X
5 Carrier Cover 15 — — — 40869 40869
6 Gasket/RTV Silicone Sealant 16 — — — 38615 38615
7 Plug – Carrier Cover 17 — — — 43180 43180
8 Gear – Differential (std) 26 — — — 33213 33213
9 Thrustwasher – Diff Gear (std) 28 — — — 40027 40027
10 KIT – Right Knuckle Assembly - 74386X 74507X 74386X 74507X 74386X
11 KIT – Left Knuckle Assembly - 74387X 74508X 74387X 74508X 74387X
12 KIT – Socket Assembly - 706944X 706944X 706944X 706944X 706944X
13 Nut – Slotted 32 43682 43682 43682 43682 43682
14 Adjusting Split Ring 34 40586 40586 40586 40586 40586
15 Socket Assembly 35 40583 40583 40583 40583 40583
16 Nut – Hex Jam / Slotted 36 40584 40584 40584 40584 40584
17 Socket Assembly 37 40916 40916 40916 40916 40916
18 Snap Ring 38 — — — — —
19 Bolt – Knuckle 39 41027 41027 41027 41027 41027
20 Right Knuckle 40 44181 44322 44181 44322 44181
21 Left Knuckle 41 44182 44323 44182 44323 44182
22 Slinger – Spindle Yoke (Inner) 46 — — — 46849 46849
23 Slinger – Spindle Yoke (Outer) 47 — 46988 — 46988 —
24 KIT – Spindle Seal & Bearing - — — — — —
25 KIT – Spindle - — — — — —
26 Oil Seal 48 — — — — —
27 Oil Seal (block vee) 49 — — — — —
28 Spacer – Wheel Bearing Spindle 50 — — — — —
29 Needle Bearing Assembly 51 — — — — —
30 Spindle – Wheel Bearing 52 — — — — —
31 KIT – Inner Wheel Bearing 55 — — — — —
32 KIT – Outer Wheel Bearing 57 — — — — —
33 Lockwasher – Wheel Bearing 58 — — — — —
34 Nut – Wheel Bearing 59 — — — — —
35 Lockwasher – Wheel Bearing Nut 60 — — — — —
36 Gasket – Drive Flange 61 — — — — —
37 Flange – Axle Drive 62 — — — — —
38 Snap Ring 63 — — — — —
39 Hub Cap 64 — — — — —
40 Lockwasher 66 — — — — —
41 Hub Assembly 67 43355 43355 43355 43355 43355
42 Tone Ring (ABS)/Slinger 72 44646 — 44646 — 44646
43 Spring – Wave Washer 73 45749 45749 45749 45749 45749
(See next page for additional bills of material)
Jeep Model 30 /181 Front
