X510-9
229
Kits & Parts - Use With All Applications
Bills of Material
Variable Parts Listing
Description & Item Number
(Refer to "Exploded View" at the
front of this section)
605303 605400 605461 605632 605717
605445
1 KIT – Inner Pinion Bearing 3 707065X 707065X 707065X 707065X 707065X
2 PKG – Pinion Bearing Shim - 707066X 707066X 707066X 707066X 707066X
3 PKG – Diff & Pinion Bearing Shim - 708036 708036 708036 708036 708036
4 End Yoke Assembly (inc 10) 9 3-4-11081-1X 3-4-11081-1X 3-4-11081-1X 3-4-11081-1X 3-4-11081-1X
5 Slinger – End Yoke 10 42432 42432 42432 42432 42432
6 KIT – Carrier Cover - 707070X 707070X 707231X 707231X 707231X
7 Carrier Cover 13 42434 42434 42434 42434 42434
8 Plug – Carrier Cover 14 36472 36472 38637 38637 38637
9 Bolt – Carrier Cover (qty 10) 15 34822 34822 34822 34822 34822
10 KIT – Differential Outboard Spacer 20 707069X (9) 707069X (9) 707069X (9) 707069X (9) 707069X (9)
11 PKG – Differential Bearing Shim 21 708035 708035 708035 708035 708035
12 Gear – Differential (std) 26 42411 43652 43652 43652 43652
13 Oil Seal (Inner Wheel) 30 42446 42446 44303 44303 44303
14 Bearing Cone – Inner Wheel 31 566025 566025 566025 565962 565962
15 Bearing Cone – Outer Wheel 33 565907 565907 565907 566057 566057
16 Retainer – Wheel Bearing (RH) 34 43075 43075 — — 46471
17 Retainer – Wheel Bearing (LH) - 43076 43076 — — 46471
18 Gasket 35 42445 42445 45817 45817 42445
19 Screw & Lockwasher Assembly 37 42447 42447 45816 45816 45816
20 Shaft – Differential (t/l) 40 — — — — —
21 Gear – Differential (t/l) 41 — — — — —
22 Thrustwasher – Pinion (t/l) 42 — — — — —
23 Pinion – Differential (t/l) 43 — — — — —
24 KIT – Disc & Plate (t/l) - — — — — —
25 Bolt – Differential Case (t/l) 47 — — — — —
26 Retainer Ring / O-Ring 48 — — 36637 36637 —
27 Spindle Nut 49 — — 36635 36635 —
28 Lockwasher – Spindle Nut 50 — — 36636 36636 —
(See next page for additional bills of material)
Ford Model 80 /286 Rear Axles
(9) 701133X & 707069X contain bearing preload spacers which can be purchased separately. See Differential Bearing Adjustment Shim
Table, at the back of the Ford section of this catalog, for thickness applications. The bearing cone spacer (44849) can be purchased
separately in kit 701152X.
