Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 187)

X510-9
187
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
605569 605623 605624 605639 605670
1 PKG – Diff & Pinion Bearing Shim - 706375X 706838X 706375X 706375X 706375X
2 PKG – Diff & Pinion Bearing Shim - 706359X 706836X 706359X 706359X 706359X
3 Baffle – Pinion Bearing 5 30982 30982 30982 30982 30982
4 End Yoke/Companion Flange Assy 10 2-4-8051X 2-4-8051X 3-4-13031-1X 2-4-8051X 3-4-13031-1X
5 Slinger – End Yoke 11 41195 41195 41195 41195 41195
6 KIT – Carrier Cover - 707217X 707217X 707217X 707217X 707217X
7 Carrier Cover 14 42799-2 42799-2 42799-2 42799-2 42799-2
8 Bolt – Carrier Cover 15 34822 34822 34822 34822 34822
9 Plug – Carrier Cover 16 43181 43181 43181 43181 43181
10 KIT – Differential Bearing 20 706047X 706047X 706047X 706047X 706047X
11 PKG – Differential Bearing Shim 21 708012 708012 708012 708012 708012
12 Bolt – Drive Gear (qty 12) 23 30266 30266 30266 30266 30266
13 Gear – Differential (std) 25 39232 39232 34394 34394 34394
14 Spacer\Shim – Differential Bearing 29 42563 42563 42563 42563 42563
15 Tone Ring 30 42928 42928 42928 42928 42928
16 Lock – Differential Shaft 31 40131-1 40131-1 44810 44810 44810
17 Seal – Hub (Full Float) 34 — — 46004 46004 46004
18 Spindle Nut (Full Float) 38 — — 43075 43075 43075
19 Spindle Nut (Full Float - LH) - — — 43075 43075 43075
20 KIT – Unit Bearing & Seal (Semi Float) - 706847X 706847X — — —
21 Seal – Inboard Oil 42 39246 39246 — — —
22 Gear – Differential (t/l) 46 — — — — —
23 Bolt – Axle Shaft (Full Float) 49 — — 45720 45720 45720
24 Bolt – Axle Shaft (Semi Float) 50 44827 44827 — — —
25 KIT – Differential Plate & Disc (t/l) - 707083X — 707083X 707083X 707083X
26 KIT – RH Rear Axle Shaft - 706846-17X 706846-17X — — —
27 KIT – LH Rear Axle Shaft - 706846-18X 706846-18X — — —
605684 605685 605700 605713 605750
1 PKG – Diff & Pinion Bearing Shim - 706375X 706375X 706375X 706375X 706375X
2 PKG – Diff & Pinion Bearing Shim - 706359X 706359X 706359X 706359X 706359X
3 Baffle – Pinion Bearing 5 30982 30982 30982 30982 30982
4 End Yoke/Companion Flange Assy 10 2-4-8051X 3-4-13031-2X 2-4-8051X 3-4-13031-2X 2-4-8051X
5 Slinger – End Yoke 11 41195 41195 41195 41195 41195
6 KIT – Carrier Cover - 707217X 707217X 707217X 707217X 707217-X
7 Carrier Cover 14 42799-2 42799-2 42799-2 42799-2 42799-2
8 Bolt – Carrier Cover 15 34822 34822 34822 34822 34822
9 Plug – Carrier Cover 16 43181 43181 43181 43181 43181
10 KIT – Differential Bearing 20 706047X 706047X 706047X 706047X 706047X
11 PKG – Differential Bearing Shim 21 708012 708012 708012 708012 708012
12 Bolt – Drive Gear (qty 12) 23 40638 40638 30266 30266 40638
13 Gear – Differential (std) 25 34394 45744 39232 34394 39232
4 Spacer\Shim – Differential Bearing 29 42563 42563 42563 42563 42563
15 Tone Ring 30 42928 42928 42928 42928 42928
16 Lock – Differential Shaft 31 44810 44810 40131-1 44810 40131-1
17 Seal – Hub (Full Float) 34 46004 46004 — 46004 —
18 Spindle Nut (Full Float) 38 43075 — — 43075 —
19 Spindle Nut (Full Float - LH) - 43075 — — 43075 —
20 KIT – Unit Bearing & Seal (Semi Float) - — — 706847X — 706847X
21 Seal – Inboard Oil 42 — 39246 39246 — 39246
22 Gear – Differential (t/l) 46 — — — — —
23 Bolt – Axle Shaft (Full Float) 49 45720 45720 — 45720 —
24 Bolt – Axle Shaft (Semi Float) 50 — — 46426 — 46426
25 KIT – Differential Plate & Disc (t/l) - 707083X 707083X 707083X 707083X 707083X
26 KIT – RH Rear Axle Shaft - — — — — —
27 KIT – LH Rear Axle Shaft - — — — — —
(See next page for additional bills of material)
Ford Model 60 /248 Rear Axles
