Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 61)

X510-9
61
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
610729 610730 610731 610732 610738
1 Seal - Pinion Oil 8 42449 42449 — — 42449
2 Slinger – End Yoke 9 34592 34592 — — 34592
3 End Yoke Assembly (inc 9) 10 2-4-7681-1X 2-4-7681-1X — — 2-4-7681-1X
4 KIT - Carrier Cover - 707335X 707335X — — 707335X
5 Pinion - Differential 23 46354 46354 — — 46354
6 Gear - Differential 24 46355 46355 — — 46355
7 Thrustwasher - Differential Gear 26 46146 46146 — — 46146
8 Seal - Tube (left side) 29 620216 620216 — — 620216
9 Cotter Pin 30 500024-9 500024-9 500024-9 500024-9 500024-9
10 Shaft & Slinger Assembly - 75689X — 74777X — 75689X
11 Shaft/Slinger/Tone Ring Assy (ABS) 45 — 75690X — 75356X —
12 Spacer - Flat 47 45935 45935 45935 45935 45935
13 Clutch Collar 65 46401 46401 — — 46401
14 Seal - Tube (right side) 67 43154 43154 — — 43154
15 Output Shaft 68 45531 45531 — — 45531
16 Bushing / Bearing 69 566008 566008 — — 566008
610739 610745 610746 610808 610810
610809
1 Seal - Pinion Oil 8 42449 42449 42449 42449 42449
2 Slinger – End Yoke 9 34592 34592 34592 34592 34592
3 End Yoke Assembly (inc 9) 10 2-4-7681-1X 2-4-7681-1X 2-4-7681-1X 2-4-7681-1X 2-4-7681-1X
4 KIT - Carrier Cover - 707335X 707335X 707335X 707335X 707335X
5 Pinion - Differential 23 46354 46354 46354 46354 46354
6 Gear - Differential 24 46355 46355 46355 46355 46355
7 Thrustwasher - Differential Gear 26 46146 46146 46146 46146 46146
8 Seal - Tube (left side) 29 620216 620216 620216 620216 620216
9 Cotter Pin 30 500024-9 500024-9 500024-9 500024-9 500024-9
10 Shaft & Slinger Assembly - — 75689X — 75689X 75689X
11 Shaft/Slinger/Tone Ring Assy (ABS) 45 75690X — 75690X — — (9)
12 Spacer - Flat 47 45935 45935 45935 45935 45935
13 Clutch Collar 65 46401 46401 46401 46401 46401
14 Seal - Tube (right side) 67 43154 43154 43154 43154 43154
15 Output Shaft 68 45531 45531 45531 45531 45531
16 Bushing / Bearing 69 566008 566008 566008 566008 566008
610811 610812 610813
1 Seal - Pinion Oil 8 42449 — —
2 Slinger – End Yoke 9 34592 — —
3 End Yoke Assembly (inc 9) 10 2-4-7681-1X — —
4 KIT - Carrier Cover - 707335X — —
5 Pinion - Differential 23 46354 — —
6 Gear - Differential 24 46355 — —
7 Thrustwasher - Differential Gear 26 46146 — —
8 Seal - Tube (left side) 29 620216 — —
9 Cotter Pin 30 500024-9 500024-9 500024-9
10 Shaft & Slinger Assembly - — 74777X 74777X
11 Shaft/Slinger/Tone Ring Assy (ABS) 45 75690X — — (9)
12 Spacer - Flat 47 45935 48355 48355
13 Clutch Collar 65 46401 — —
14 Seal - Tube (right side) 67 43154 — —
15 Output Shaft 68 45531 — —
16 Bushing / Bearing 69 566008 — —
Dodge Model 60 /248 Disconnect Front Axles
(9) Contact vehicle manufacturer - Tone ring is provided with the hub, rotor and bearing assembly.
