Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 255)

255
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" below
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
X510-9
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
GM / Chevrolet 44 /216 Rear Axles for F-Car
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 706031X KIT – Inner Pinion Bearing
4 — Inner Pinion Bearing Shims
(see shim packages)
5 — Baffle – Pinion Bearing
6 — Outer Pinion Bearing Shims
(see shim packages)
701067X PKG – Diff & Pinion Bearing Shim
(inc items 4, 6, 21)
701066X PKG – Pinion Bearing Shim
(inc items 4, 6)
7 706030X KIT – Outer Pinion Bearing
8 41012 Slinger – Outer Pinion Bearing
9 — (2) Seal – Pinion Oil
10 — (2) End Yoke Assembly (inc 11)
11 41498 Slinger – End Yoke
12 30186 Washer – Pinion Nut
13 30185 Pinion Nut
707109X KIT – Carrier Cover
(inc items 14, 15, 16)
14 42960-2 Carrier Cover
15 43180 Plug – Carrier Cover
16 34279 Bolt – Carrier Cover
17 38615 RTV Silicone Sealant
18 — (3) Differential Bearing Cap
19 48632-1 Bolt – Differential Bearing Cap
20 706032X KIT – Differential Bearing
21 701005X PKG – Diff & Pinion Bearing Shim
22 — (4) Case – Differential (t/l)
23 41221 Bolt – Drive Gear (qty 10)
24 41193 Pinion – Differential (t/l)
25 46618 Gear – Differential (t/l)
26 13338-3 Thrustwasher – Diff Pinion (t/l)
27 39194 Shaft – Differential
28 13449 Lock – Differential Shaft
706352X KIT – Differential Plate & Disc (t/l)
(inc items 29, 30, 31, 32)
29 — (4) Plate – Differential Dished
30 — (4) Disc – Differential
31 — (4) Plate – Differential
32 40835 Clip – Differential Clutch Retainer
706989X KIT – Unit Bearing and Seal
(inc items 33, 34, 35, 36)
33 36121 Retainer Ring – Wheel Bearing
34 565909 Wheel Bearing Assembly
35 35938 Seal – Outboard Shaft
36 41181 Oil Seal Retainer
37 40544 Wheel Bolt
38 — (3) Bolt – Brake Mounting
39 — (3) Nut – Brake Mounting
40 — (1) Shaft – Axle Flange Drive
Kits & Parts - Use With All Applications
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Variable Parts Listing
605218 605558
1 Seal – Pinion Oil 9 39118 41455
2 End Yoke Assembly (inc 11) 10 2-4-3581-1X (10) 2-4-8091X
(10) Bearing strap kit used with end yoke.
