103
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
(5) Service Power Lok ratios 3.54 Case Assembly or Case Kit with 708054 Trak Lok
Service Power Lok ratios 4.10 Case Assembly or Case Kit with 708052 Trak Lok
The 708054 & 708052 Trak Lok uses 708051 Inner Parts Kit
Note: See cross shaft view illustration on previous page for the difference between a Power Lok and a Trak Lok case.
X510-9
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
Dodge Model 80 /286 Rear Axles
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 707065X KIT – Inner Pinion Bearing
707066X PKG – Pinion Bearing Shim
(inc items 4, 5, 11, 12)
708036 PKG – Diff & Pinion Bearing Shim
(inc items 4, 5, 11, 12, 21)
4 — (4) Inner Pinion Shims
(see shim packages)
5 — (4) Outer Pinion Shims
(see shim packages)
6 707064X KIT – Outer Pinion Bearing
7 42430 Thrustwasher – Bearing
8 — (2) Seal – Pinion Oil
9 231872 Seal – Deflector
10 3-4-11081-1X End Yoke Assembly (inc 9)
11 37104 Washer – Pinion Nut
12 37082 Pinion Nut
— (2) KIT – Carrier Cover
(inc items 13, 14, 15)
13 — (2) Carrier Cover
14 38637 Plug – Carrier Cover
15 34822 Bolt – Carrier Cover
16 38615 RTV Silicone Sealant
17 — (3) Differential Bearing Cap
18 48632-1 Bolt – Differential Bearing Cap
19 707069X KIT – Outboard Bearing Spacer
20 706070X KIT – Differential Bearing
21 708035 PKG – Differential Bearing Shim
22 — (1) Case – Differential (std)
23 42413 Pinion – Differential (std)
24 35082 Thrustwasher – Differential Pinion
25 42411 Gear – Differential (std)
26 34729 Thrustwasher – Differential Gear
27 46640 Shaft – Differential
28 47024 Lock – Differential Shaft
29 42433 Bolt – Drive Gear
30 42414 Tone Ring (ABS)
31 — (2) Seal – Hub
32 — (3) KIT – Inner Wheel Bearing
33 — (3) Hub Assembly
34 — (3) KIT – Outer Wheel Bearing
35 — (2) Spindle Nut
36 46545 Locking Wedge
37 39697 Gasket
38 — (1) Shaft – Axle
39 — (2) Flange Head Screw
40 — (1) Case – Differential (p/l / t/l)
41 41610-1 Flange Head Screw
42 070SS105 Shaft – Differential (p/l)
42A 47802 Shaft – Differential (t/l)
43 31040 Pinion – Differential (p/l)
43A 47798 Pinion – Differential (t/l)
44 46394 Gear – Differential (p/l)
44A 47796 Gear – Differential (t/l)
45 46395 Ring – Differential Gear (p/l)
701129X (5) KIT – Disc & Plate (t/l)
702009 (5) KIT – Disc & Plate (p/l)
46 — (4) Disc – Differential Dished (p/l)
46A — (4) Disc – Differential Dished (t/l)
47 — (4) Plate – Differential Pressure (p/l)
47A — (4) Plate – Differential Pressure (t/l)
48 — (4) Disc – Differential Clutch (p/l)
48A — (4) Disc – Differential Clutch (t/l)
49 — Thrustwasher – Pinion Diff (t/l)
