Spicer FRONT AND REAR LIGHT AXLE PARTS, KITS AND APPLICATIONS - Manual (Page 377)

Jeep Model 70 /267 Rear
1 — (3) Housing – Axle Service
2 706998-5X Drive Pinion & Gear Assembly
3 706861X KIT – Inner Pinion Bearing
4 — Inner Pinion Bearing Shims
(see shim packages)
706862X PKG – Pinion Bearing Shim
(inc items 4, 6, 12, 13)
5 41550 Baffle – Pinion Bearing
6 — Outer Pinion Bearing Shims
(see shim packages)
708020 KIT – Diff & Pinion Bearing Shim
(inc items 4, 6, 13, 17, 21)
7 706045X KIT – Outer Pinion Bearing
8 42737 Thrustwasher – Bearing
9 42449 Seal – Pinion Oil
10 34592 Slinger – End Yoke
11 2-4-3801-1X End Yoke Assembly (inc 10)
12 30275 Washer – Pinion Nut
13 30271 Pinion Nut
707104X KIT – Carrier Cover
(inc items 14, 15, 16)
14 42815-2 Carrier Cover
15 43180 Plug – Carrier Cover
16 34822 Bolt – Carrier Cover (qty 10)
17 34687 Gasket – Carrier Cover
18 — (3) Differential Bearing Cap
19 48632-1 Bolt – Differential Bearing Cap
20 706047X KIT – Differential Bearing
21 708012 KIT – Diff Bearing Shim (inc 17)
22 — (4) Case – Differential (std)
23 30266 Bolt – Drive Gear (qty 12)
24 35080 Pinion – Differential (std)
25 35079 Gear – Differential (std)
26 35082 Thrustwasher – Diff Pinion (std)
27 34729 Thrustwasher – Diff Gear (std)
28 46640 Shaft – Differential (std)
29 47024 Lock – Differential Shaft
30 — (3) Bolt – Brake Mounting
31 — (3) Nut – Brake Mounting
32 39693 Seal – Hub
33 — (3) KIT – Inner Wheel Bearing
34 — (3) KIT – Outer Wheel Bearing
35 — (3) Wheel Hub
36 39695 Spindle Nut
37 41373 Locking Wedge
38 39697 Gasket
39 — (1) Shaft – Axle Flange Drive
40 — (4) Case – Differential (p/l)
41 42522 Ring – Differential Gear
707075X KIT – Differential Plate & Disc (p/l)
(inc items 43, 44, 45)
42 — (4) Plate – Differential
43 — (4) Disc – Differential(dished)
43161 Friction Modifier
44 — (4) Plate – Differential
45 35294 Gear – Differential(p/l)
46 31040 Pinion – Differential (p/l)
47 31041 Shaft – Differential (p/l)
48 41610-1 Bolt – Differential Case
49 36526 Lockwasher
50 39694 Bolt – Axle Shaft
51 46176 Spacer – Flat
377
(1) See "Bill of Material Table" below
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
X510-9
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
Bill of Material Table
1985 CJ 10A Military
605242-1 Powr Lok 4.88 706998-5X 706050X 706054X 706057X 36113-25 36113-24
605242-2 Standard 4.88 706998-5X 706052X 706056X 706058X 36113-25 36113-24
