1998 1/2-99 F-250/350 SRW (4x4) ABS
610654-1 Standard 3.73 76127-5X (9) 707459X 706917X 706916X 76110-1X 76110-2X
610654-2 Standard 4.10 660319-5 (9) 707459X 706917X 706916X 76110-1X 76110-2X
610654-3 Standard 4.30 76136-5X (9) 707459X 706917X 706916X 76110-1X 76110-2X
1998 1/2-99 F-250/350 SRW (4x4)
610659-1 Standard 3.73 76127-5X (9) 707459X 706917X 706916X 76110-1X 76110-2X
610659-2 Standard 4.10 660319-5 (9) 707459X 706917X 706916X 76110-1X 76110-2X
610659-3 Standard 4.30 76136-5X (9) 707459X 706917X 706916X 76110-1X 76110-2X
157
(1) See "Bill of Material Table" below
(3) Contact Vehicle Manufacturer
X510-9
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
Ford Model 50 /229 Front Axles
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 701112X PKG – Inner Pinion Bearing Shim
701160X PKG – Diff & Pinion Bearing Shim
4 706015X KIT – Inner Pinion Bearing
5 44896 Collapsible Spacer
6 706030X KIT – Outer Pinion Bearing
7 13575 Slinger – Outer Pinion Bearing
8 47761 Seal – Pinion Oil
9 47762 Seal – End Yoke
10 3-4-13761-1 End Yoke Assembly
11 30186 Washer – Pinion Nut
12 30185 Pinion Nut
13 47707-1 Carrier Cover
14 43180 Plug – Carrier Cover
15 47508 Bolt – Carrier Cover (qty 9)
16 38615 RTV Silicone Sealant
17 — (3) Differential Bearing Cap
18 48632-1 Bolt – Differential Bearing Cap
19 700097 KIT – Differential Bearing
20 701006X PKG – Differential Bearing Shim
21 — (1) Case – Differential
22 45784 Bolt – Drive Gear (qty 10)
23 620436 Pinion – Differential
24 40432 Gear – Differential
25 620439 Thrustwasher – Differential Pinion
26 50718 Thrustwasher – Differential Gear
27 620414 Shaft – Differential
28 44810 Lock – Differential Shaft
29 48773 Oil Seal
700238-2X KIT – Socket Assembly
(inc items 30, 31, 33, 34, 35, 36)
30 500024-8 Cotter Pin
31 44101 Nut – Hex Slotted
32 44507 Bushing
33 47184 Upper Socket Assy
34 44133 Lock Nut
35 47185 Lower Socket Assy
36 620343 Snap Ring
37 — (3) Knuckle
38 48660 Nut – Knuckle
39 50381 Oil Seal
40 — (1) Shaft & Joint Assembly
41 50491 Oil Seal
42 47766 Thrustwasher
43 47758 Dust Shield
44 — (3) Hub Assembly
701166X PKG – Thrustwasher (inc 45, 46)
45 47760 Thrustwasher
46 47759 Thrustwasher
47 620142 Snap Ring
48 47742 Baffle – Pinion Bearing
49 41784-2 O-Ring
Bill of Material Table
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
(9) Gear set includes ring, pinion and drive gear screws.
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit
(7) Case Assy. Kit (8) Case Kit Inner Parts Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
