X510-9
292
Kits & Parts - Use With All Applications
Bills of Material
Variable Parts Listing
Description & Item Number
(Refer to "Exploded View"
at the front of this section)
610234 610244 610256 610269 610280
610237
1 Seal – Pinion Oil 10 39118 39118 39118 39118 39118
2 End Yoke or Assembly (inc 12) 11 — 2-4-8091-1X — 2-4-8091-1X 2-4-6561-1
3 Slinger – End Yoke 12 — 41498 — 41498 —
4 KIT – Carrier Cover - — 707049X — 706943X 706943X
5 Carrier Cover 15 — 36538 — 40869 40869
6 Gasket/RTV Silicone Sealant 16 — 38615 — 38615 39615
7 Plug – Carrier Cover 17 — 36918 — 36924 36924
8 Gear – Differential (std) 26 — 33213 — 620486 620486
9 Thrustwasher – Diff Gear (std) 28 — 34095 — 40027 40027
10 KIT – Right Knuckle Assembly - — 700074 — — —
11 KIT – Left Knuckle Assembly - — 700075 — — —
12 KIT – Socket Assembly - 706944X 706116X 706944X 706944X 706944X
13 Nut – Slotted 32 43682 35416 43682 43682 43682
14 Adjusting Split Ring 34 40586 35417 40586 40586 40586
15 Socket Assembly 35 40583 40112 40583 40583 40583
16 Nut – Hex Jam / Slotted 36 40584 35566 40584 40584 40584
17 Socket Assembly 37 40916 40113 40916 40916 40916
18 Snap Ring 38 — 35928 — — —
19 Bolt – Knuckle 39 41027 36326-1 — 41027 41027
20 Right Knuckle 40 40707 41535 — 40707 40707
21 Left Knuckle 41 40579 41536 — 40579 40579
22 Slinger – Spindle Yoke (Inner) 46 — 35168 — 46849 46849
23 Slinger – Spindle Yoke (Outer) 47 — 36364 — 40589 40589
24 KIT – Spindle Seal & Bearing - — 706527X — — —
25 KIT – Spindle - — 706537X — — —
26 Oil Seal 48 — 36361 — — —
27 Oil Seal (block vee) 49 — 38128 — — —
28 Spacer – Wheel Bearing Spindle 50 — 38106 — — —
29 Needle Bearing Assembly 51 — 550759 — — —
30 Spindle – Wheel Bearing 52 — 38148 — — —
31 KIT – Inner Wheel Bearing 55 — 706578X — — —
32 KIT – Outer Wheel Bearing 57 — 706111X — — —
33 Lockwasher – Wheel Bearing 58 — 17015 — — —
34 Nut – Wheel Bearing 59 — 17016 — — —
35 Lockwasher – Wheel Bearing Nut 60 — 17017 — — —
36 Gasket – Drive Flange 61 — 18188 — — —
37 Flange – Axle Drive 62 — 36436 — — —
38 Snap Ring 63 — 18270 — — —
39 Hub Cap 64 — 32001 — — —
40 Lockwasher 66 — 501209-3 — — —
41 Hub Assembly 67 40592 — — 40592 40592
42 Tone Ring (ABS)/Slinger 72 — — — — —
43 Spring – Wave Washer 73 — — — — —
(See next page for additional bills of material)
Jeep Model 30 /181 Front
