(1) See "Bill of Material Table" below
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
X510-9
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
Parts Listing
1 — (3) Housing – Axle Service
2 — (1) Drive Pinion & Gear Assembly
3 620878-1 Collapsible Spacer
707223X PKG – Diff & Pinion Bearing Shim
(inc items 3, 5, 12, 13, 21, 24)
4 706123X KIT – Inner Pinion Bearing
5 — (4) Inner Pinion Bearing Shims
(see shim packages)
707222X PKG – Inner Pinion Bearing Shim
(inc items 3, 5, 12, 13, 24)
6 43734 Baffle
7 706894X KIT – Outer Pinion Bearing
8 36714 Slinger – Pinion Bearing Outer
9 40554 Seal – Pinion Oil
10 2-1-2651X Companion Flange Assy (inc 11)
11 232001 Slinger – Companion Flange
12 30186 Washer – Pinion Nut
13 30185 Pinion Nut
707224X KIT – Carrier Cover (inc 14, 17)
14 43008 Carrier Cover
15 38615 RTV Silicone Sealant
16 41874 Plug – Carrier Cover
17 40286-5 Bolt – Carrier Cover (qty 10)
18 — (4) Cap – Differential Bearing
19 620752 Bolt – Differential Bearing Cap
20 706893X KIT – Differential Bearing
21 706896X PKG – Diff Bearing Shim (inc 15, 24)
22 — (4) Case – Differential (std)
23 41221 Bolt – Drive Gear (qty 10)
24 42570 Snap Ring
25 32926 Pinion – Differential
26 40380 Gear – Differential
27 34096 Thrustwasher – Differential Pinion
28 620875 Thrustwasher – Differential Gear
29 41648 Shaft – Differential
30 13449 Lock – Differential Shaft
31 45916 Oil Seal
32 565987 Bearing Assembly
33 — (1) Shaft & Joint Assembly
Bill of Material Table
(7) See Ring Gear & Pinion Kits in XGI Catalog for ratio & tooth combinations.
(8) See Differential Case Assy Kits in XGI Catalog for spline data & ratios.
145
1990-92 Aerostar
610303-1 Standard 3.73 707221-1X 706974X 706975X 706890X 43159 43157
610303-2 Standard 3.27 707221-2X 706974X 706975X 706890X 43159 43157
1992 1/2 Aerostar
610369-1 Standard 3.73 707221-1X 706974X 706975X 706890X 44102 44100
610369-2 Standard 3.27 707221-2X 706974X 706975X 706890X 44102 44100
1992 1/2-97 Aerostar
610448-1 Standard 3.73 707221-1X 706974X 706975X 706890X 44102 44100
610448-2 Standard 3.27 707221-2X 706974X 706975X 706890X 44102 44100
Ford Model 28 /174 Front Axles
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit
(7) Case Assy. Kit (8) Case Kit Inner Parts Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
