REAR AXLE SHAFTS
Dimensions & Components
XGI
91
Complete
Shaft Assy.
Part Number
Bolt Circle
Number of
Bolts
Float
Length of
Flange Face to
End of Shaft
D
Spline Dia. &
Number of
Teeth
A
Flange
Diameter
C
Spline
Length
B
26860-1X 28.78 1.50 - 35 1.81 7.06 5.50 5 SEMI
27436X 31.08 1.50 - 35 1.62 6.00 4.50 8 SEMI
27438X 30.11 1.50 - 35 1.62 6.00 4.50 8 SEMI
28497-14X 27.91 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-13X 30.45 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-12X 32.45 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-9X 27.44 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-8X 29.44 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-7X 28.81 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-5X 29.81 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-4X 34.14 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-3X 22.78 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-2X 31.68 1.31 - 30 1.81 7.06 5.50 6 SEMI
28497-1X 25.24 1.31 - 30 1.81 7.06 5.50 6 SEMI
29699-2X 23.06 1.50 - 35 1.62 6.00 4.50 5 SEMI
29699-1X 27.06 1.50 - 35 1.62 6.00 4.50 5 SEMI
29700-2X 24.11 1.50 - 35 1.62 6.00 4.50 5 SEMI
29700-1X 28.11 1.50 - 35 1.62 6.00 4.50 5 SEMI
34551-3 25.87 1.31 - 30 1.81 4.50 3.72 8 SEMI
35455-4 31.82 1.31 - 30 1.81 7.06 5.50 5 SEMI
35455-3 30.94 1.31 - 30 1.81 7.06 5.50 5 SEMI
35455-2 30.13 1.31 - 30 1.81 7.06 5.50 5 SEMI
35455 27.31 1.31 - 30 1.81 7.06 5.50 5 SEMI
35488-19 22.20 1.31 - 30 1.81 7.06 5.50 5 SEMI
35508-2 34.78 1.50 - 35 1.81 7.06 5.50 5 SEMI
35508-1 28.78 1.50 - 35 1.81 7.06 5.50 5 SEMI
36041 31.21 1.31 - 30 1.81 6.37 5.00 5 SEMI
70165-2X 32.61 1.31 - 30 1.81 7.06 5.50 5 SEMI
70165-1X 31.11 1.31 - 30 1.81 7.06 5.50 5 SEMI
70386-2X 32.61 1.31 - 30 1.81 7.06 5.50 5 SEMI
70386-1X 31.11 1.31 - 30 1.81 7.06 5.50 5 SEMI
70416-2X 32.61 1.31 - 30 1.81 7.06 5.50 5 SEMI
70416-1X 31.11 1.31 - 30 1.81 7.06 5.50 5 SEMI
70417-2X 32.61 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-12X 26.16 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-11X 34.47 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-10X 22.19 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-9X 24.69 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-8X 23.31 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-7X 26.94 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-6X 29.25 1.31 - 30 1.81 7.06 5.50 5 SEMI
706028-5X 31.44 1.31 - 30 1.81 7.06 5.50 5 SEMI
706092-6X 28.81 1.31 - 30 1.81 7.06 5.50 6 SEMI
706092-5X 29.81 1.31 - 30 1.81 7.06 5.50 6 SEMI
706092-4X 34.14 1.31 - 30 1.81 7.06 5.50 6 SEMI
706092-3X 22.78 1.31 - 30 1.81 7.06 5.50 6 SEMI
706092-2X 31.69 1.31 - 30 1.81 7.06 5.50 6 SEMI
706092-1X 25.24 1.31 - 30 1.81 7.06 5.50 6 SEMI
