Front axle shafts – Spicer Axle General Information User Manual
Page 73
FRONT AXLE SHAFTS
Dimensions & Components
XGI
67
Axle Shaft Assy
Outer Shaft Spindle End
Inner Shaft Side Gear
Complete
Overall
Yoke Shaft
Yoke Shaft
Assembly
Length
Part
Slinger
Part
Slinger
Number
Number
Number
Length
Length
A
C
E
28478
USES U-JOINT KIT 5-760X
B = 1.50 - 35
D = 1.31 - 30
-1X
23.49
6.59
36990
38414
16.90
27902-5X
-
-2X
43.69
6.59
36990
38414
37.10
27902-18X
-
-3X
22.70
6.59
36990
38414
16.11
27902-25X
-
-4X
43.09
6.59
36990
38414
36.50
27902-8X
-
-5X
41.98
6.59
36990
38414
35.41
27902-6X
-
-6X
26.48
6.59
36990
38414
19.91
27902-36X
-
29508
USES U-JOINT KIT 5-760X
B = 1.25 - 19
D = 1.31 - 30
-1X
45.41
10.66
37951
36364
34.75
27902-35X
-
-2X
29.64
10.66
37951
36364
18.62
27902-31X
-
29833
USES U-JOINT KIT 5-760X
B = 1.25 - 19
D = 1.31 - 30
-1X
28.43
9.94
38347
36364
18.50
27902-1X
-
-2X
46.06
9.94
38347
36364
36.13
27902-2X
-
-4X
43.12
9.94
38347
36364
33.19
27902-20X
-
-5X
26.56
9.94
38347
36364
16.62
27902-21X
-
-6X
45.19
9.94
38347
36364
35.25
27902-22X
-
660003
USES U-JOINT KIT 5-760X
B = 1.25 - 19
D = 1.31 - 30
-1
43.62
9.72
620005
36364
33.91
27902-3X
-
-2
28.62
9.72
620005
36364
18.91
27902-4X
-
-3
44.47
9.72
620005
36364
34.75
27902-35X
-
-4
28.34
9.72
620005
36364
18.62
27902-31X
-
-5
45.12
9.72
620005
36364
35.41
27902-6X
-
-6
29.62
9.72
620005
36364
19.91
27902-36X
-
-7
21.37
9.72
620005
36364
11.66
70017-3X
-
-8
22.92
9.72
620005
36364
31.97
70017-4X
-
-9
24.53
9.72
620005
36364
14.81
27902-28X
-
-10
28.53
9.72
620005
36364
18.81
27902-29X
-
-11
32.53
9.72
620005
36364
22.81
27902-30X
-
-13
26.53
9.72
620005
36364
16.81
27902-46X
-
-14
40.53
9.72
620005
36364
30.81
27902-47X
-
660029
USES U-JOINT KIT 5-260X
B = 1.25 - 19
D = 1.31 - 30
-1
37.66
9.72
620043
36364
27.94
27553-11X
35168
-2
28.03
9.72
620043
36364
18.31
27553-5X
35168
660048
USES U-JOINT KIT 5-806X/SPL55-3X
B = 1.31 - 30
D = 1.50 - 35
-1
45.96
11.40
620085
37308
34.56
660182-10
-
-2
30.08
11.40
620085
37308
18.68
660182-11
-
-4
48.08
11.40
620085
37308
36.68
660182-36
-
-5
27.36
11.40
620085
37308
15.96
660182-1
-
660091
USES U-JOINT KIT 5-760X
B = 1.25 - 19
D = 1.31 - 30
-3
24.62
9.93
620134
36364
14.69
27902-19X
-
-4
43.12
9.93
620134
36364
33.19
27902-20X
-
-5
26.56
9.93
620134
36364
16.63
27902-21X
-
-6
45.18
9.93
620134
36364
35.25
27902-22X
-
-9
42.05
9.93
620134
36364
32.12
27902-16X
-
-22
27.64
9.93
620134
36364
17.72
27902-50X
-
-23
44.09
9.93
620134
36364
34.17
27902-51X
-
-24
25.72
9.93
620134
36364
15.80
27902-52X
-
