REAR AXLE SHAFTS
Dimensions & Components
XGI
80
Listed By Length
Length of
Flange Face to
End of Shaft
D
Bolt Circle
Number of
Bolts
Float
Complete
Shaft Assy.
Part Number
Spline Dia. &
Number of
Teeth
A
Flange
Diameter
C
Spline
Length
B
21.96
34887-30A
1.31 - 30
1.81
4.75
3.96
8
FULL
23.25
34887-23
1.31 - 30
1.81
4.75
3.96
8
FULL
30.34
31494-8
1.31 - 30
1.81
4.50
3.72
8
FULL
31.12
34887-1
1.31 - 30
1.81
4.75
3.96
8
FULL
31.12
35467-1
1.31 - 30
1.81
4.75
3.96
8
FULL
31.22
34887-13
1.31 - 30
1.81
4.75
3.96
8
FULL
31.22
35953-5
1.31 - 30
1.81
4.75
3.96
8
FULL
31.22
38378-3
1.31 - 30
1.81
4.74
3.96
8
FULL
31.22
43965-2
1.31 - 30
1.81
4.73
3.96
8
FULL
31.47
34887-4
1.31 - 30
1.81
4.75
3.96
8
FULL
31.83
35091-19
1.50 - 35
1.62
4.74
3.96
8
FULL
32.22
38378-5
1.31 - 30
1.81
4.74
3.96
8
FULL
32.81
31494-5
1.31 - 30
1.81
4.50
3.72
8
FULL
33.25
35445-1
1.31 - 16
1.81
4.75
3.96
8
FULL
33.25
35467-6
1.31 - 30
1.81
4.75
3.96
8
FULL
33.25
37560-1
1.31 - 30
1.81
4.75
3.96
8
FULL
33.35
41100-2
1.50 - 35
1.63
4.47
3.56
8
FULL
33.69
30282-1
1.31 - 16
1.81
4.75
3.96
8
FULL
33.77
37560-3
1.31 - 30
1.81
4.75
3.96
8
FULL
33.78
36113-23
1.50 - 35
1.62
4.75
3.96
8
FULL
33.78
41100-3
1.50 - 35
1.63
4.47
3.56
8
FULL
33.87
30282-4
1.31 - 16
1.81
4.75
3.96
8
FULL
33.87
34887-3
1.31 - 30
1.81
4.75
3.96
8
FULL
34.12
36113-7
1.50 - 35
1.62
4.75
3.96
8
FULL
34.17
35953
1.31 - 30
1.81
4.75
3.96
8
FULL
34.17
39260-2
1.31 - 30
1.81
4.75
3.96
8
FULL
34.17
43965-1
1.31 - 30
1.81
4.73
3.96
8
FULL
34.21
38378-1
1.31 - 30
1.81
4.74
3.96
8
FULL
34.22
34887-14
1.31 - 30
1.81
4.75
3.96
8
FULL
34.22
34887-6
1.31 - 30
1.81
4.75
3.96
8
FULL
34.24
35091-29
1.50 - 35
1.62
4.74
3.96
8
FULL
34.24
43811-1
1.37 - 32
1.62
4.72
3.96
8
FULL
34.51
39260-4
1.31 - 30
1.81
4.75
3.96
8
FULL
34.56
35445-2
1.31 - 16
1.81
4.75
3.96
8
FULL
34.56
35467-3
1.31 - 30
1.81
4.75
3.96
8
FULL
34.62
39260-1
1.31 - 30
1.81
4.75
3.96
8
FULL
34.75
31494-1
1.31 - 30
1.81
4.50
3.72
8
FULL
34.85
36113-21
1.50 - 35
1.62
4.75
3.96
8
FULL
34.92
43811-16
1.37 - 32
1.62
4.72
3.96
8
FULL
34.99
39260-7
1.31 - 30
1.81
4.75
3.96
8
FULL
