Rear axle shafts – Spicer Axle General Information User Manual
Page 93
Listed By Part Number
Complete
Shaft Assy.
Part Number
Bolt Circle
Number of
Bolts
Float
Length of
Flange Face to
End of Shaft
D
Spline Dia. &
Number of
Teeth
A
Flange
Diameter
C
Spline
Length
B
REAR AXLE SHAFTS
Dimensions & Components
XGI
87
30282-4
33.87
1.31 - 16
1.81
4.75
3.96
8
FULL
30282-1
33.69
1.31 - 16
1.81
4.75
3.96
8
FULL
31494-10
35.81
1.31 - 30
1.81
4.50
3.72
8
FULL
31494-9
41.31
1.31 - 30
1.81
4.50
3.72
8
FULL
31494-8
30.34
1.31 - 30
1.81
4.50
3.72
8
FULL
31494-6
38.81
1.31 - 30
1.81
4.50
3.72
8
FULL
31494-5
32.81
1.31 - 30
1.81
4.50
3.72
8
FULL
31494-1
34.75
1.31 - 30
1.81
4.50
3.72
8
FULL
32987-3
37.10
1.31 - 30
1.81
4.75
4.00
6
FULL
32987-1
35.78
1.31 - 30
1.81
4.75
4.00
6
FULL
33318-1
35.01
1.50 - 23
1.62
5.19
4.38
6
FULL
34414-1
35.05
1.50 - 23
1.62
4.75
3.97
8
FULL
34887-30A
21.96
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-23
23.25
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-14
34.22
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-13
31.22
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-6
34.22
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-5
37.47
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-4
31.47
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-3
33.87
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-2
40.12
1.31 - 30
1.81
4.75
3.96
8
FULL
34887-1
31.12
1.31 - 30
1.81
4.75
3.96
8
FULL
35091-29
34.24
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-28
37.31
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-20
42.79
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-19
31.83
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-18
43.58
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-17
37.83
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-12
41.51
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-11
35.76
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-10
39.44
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-9
38.64
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-4
36.94
1.50 - 35
1.62
4.74
3.96
8
FULL
35091-1
36.09
1.50 - 35
1.62
4.74
3.96
8
FULL
35103-1
35.91
1.50 - 35
1.62
5.25
4.37
6
FULL
35445-2
34.56
1.31 - 16
1.81
4.75
3.96
8
FULL
35445-1
33.25
1.31 - 16
1.81
4.75
3.96
8
FULL
35467-6
33.25
1.31 - 30
1.81
4.75
3.96
8
FULL
35467-5
44.57
1.31 - 30
1.81
4.75
3.96
8
FULL
