Ifs axle shafts – Spicer Axle General Information User Manual
Page 84
IFS AXLE SHAFTS
Dimensions & Components
XGI
Length of
Flange
Face to
Spline End
D
Bolt Circle
Number of
Bolts
Float
Complete
Shaft
Assembly
Part Num-
ber
Spline
Dia. &
Number of
Teeth
A
Flange
Diameter
C
Spline
Length
B
78
Eagle Model 30/ 181 IFS and Ford Aerostar Model 28/ 174 IFS
Listed by Length
3.876
620964
1.18 - 27
.790
5.630
4.840
6
Semi
4.796
620516
1.18 - 27
1.625
5.630
4.843
6
Semi
4.796
620842
1.18 - 27
1.625
5.630
4.843
6
Semi
4.863
43157
1.00 - 23
1.693
3.715
3.120
4
Semi
4.979
44100
1.00 - 23
1.693
3.745
3.071
6
Semi
14.870
43159
1.00 - 23
1.693
3.715
3.120
4
Semi
14.986
44102
1.00 - 23
1.693
3.745
3.071
6
Semi
20.422
620515
1.18 - 27
1.625
5.630
4.843
6
Semi
