FORD IFS AXLE SHAFTS & SLIP YOKES
Dimensions & Components
XGI
Complete
Assembly
Number
Yoke Shaft
Number
Major
Spline
Diameter
D
Slip Yoke
Part Num-
ber
U-Joint Kit
Overall
Length
A
C/L to
End of
Spline
C
Major
Spline
Diameter
B
79
Listed by Complete Assembly Number
C/L to
End of
Spline
E
660232-1
5-282X
15.14
1.31 - 30
9.89
700153
1.39 - 30/31
(35)
5.25
3-3-2861X
660396-1
5-297X
15.39
1.31 - 30
9.89
700152
1.39 - 30/31
(35)
5.50
2-3-8311X
71432-1X
5-297X
15.39
1.31 - 30
9.89
620308-1 1.39 - 30/31
(35)
5.50
2-3-8481X
71691X
5-456X
15.12
1.00 - 23
10.06
40391
1.21 - 26/28
(36)
5.06
2-3-8811X
71735-1X
5-297X
15.64
1.31 - 30
10.14
40437-1
1.39 - 30/31
(35)
5.50
2-3-8481X
71738-1X
5-282X
15.33
1.31 - 30
10.08
40438-1
1.39 - 30/31
(35)
5.25
3-3-2861X
71739-1X
5-297X
15.64
1.31 - 30
10.14
40437-1
1.39 - 30/31
(35)
5.50
2-3-8311X
72041-1X
5-297X
15.14
1.31 - 30
10.14
40437-1
1.39 - 30/31
(35)
5.06
2-3-8741X
72043-1X
5-282X
14.89
1.31 - 30
10.08
40438-1
1.39 - 30/31
(35)
4.81
3-3-3001X
73414-1X
5-297X
16.10
1.16 - 27
11.04
42571-1
1.39 - 30/31
(35)
5.06
2-3-8741X
74444-1X
5-760X
15.01
1.00 - 23
9.95
44316-1
1.39 - 30/31
(35)
5.06
2-3-8741X
(35) 1.39 - 30 based on 31 spline
(36) 1.21 - 26 based on 28 spline
