FRONT AXLE SHAFTS
Dimensions & Components
XGI
66
Listed By Complete Assembly Number
Axle Shaft Assy
Outer Shaft Spindle End
Inner Shaft Side Gear
Complete
Overall
Yoke Shaft
Yoke Shaft
Assembly
Length
Part
Slinger
Part
Slinger
Number
Number
Number
Length
Length
A
C
E
28071
USES U-JOINT KIT 5-260X
B = 1.25 - 19
D = 1.16 - 27
-1X
37.66
9.72
36575
36364
27.94
27553-11X
35168
-2X
28.03
9.72
36575
36364
18.31
27553-5X
35168
28135
USES U-JOINT KIT 5-260X
B = 1.16 - 27
D = 1.16 - 27
-1X
40.75
8.22
2-82-1391
-
32.53
27658-1X
-
-2X
24.12
8.22
2-82-1391
-
15.91
27658-2X
-
28142
USES U-JOINT KIT 5-260X
B = 1.12 - 10
D = 1.31 - 30
-1X
26.22
8.22
2-82-161
-
18.00
27656-1X
-
-2X
44.22
8.22
2-82-161
-
36.00
27656-6X
-
28173
USES U-JOINT KIT 5-760X
B = 1.25 - 19
D = 1.31 - 30
-1X
26.56
8.80
36666
36364
17.76
27902-9X
-
-2X
45.06
8.80
36666
36364
36.25
27902-10X
-
-3X
40.91
8.80
36666
36364
32.12
27902-16X
-
-4X
31.91
8.80
36666
36364
23.12
27902-17X
-
-5X
26.94
8.80
36666
36364
18.14
27902.23X
-
-6X
44.44
8.80
36666
36364
35.64
27902-24X
-
-15X
25.70
8.80
36666
36364
16.91
27902-5X
-
-16X
45.89
8.80
36666
36364
37.11
27902-18X
-
-17X
21.80
8.80
36666
36364
12.98
27902-55X
-
-18X
36.05
8.80
36666
36364
27.25
27902-56X
-
28179
USES U-JOINT KIT 5-260X
B = 1.16 - 27
D = 1.16 - 27
-1X
23.62
8.72
36617
36364
14.91
27941-1X
35168
-2X
41.75
8.72
36617
36364
33.03
27941-2X
35168
-3X
22.86
8.72
36617
36364
14.14
27941-3X
35168
-4X
35.73
8.72
36617
36364
27.02
27941-4X
35168
-5X
22.86
8.72
36617
36364
14.14
27941-7X
35168
-6X
41.43
8.72
36617
36364
32.71
27941-8X
35168
-7X
24.54
8.72
36617
36364
15.82
27941-9X
35168
-8X
37.41
8.72
36617
36364
28.69
27941-10X
35168
28360
USES U-JOINT KIT 5-260X
B = 1.25 - 19
D = 1.31 - 30
-1X
44.47
9.53
660118-1
-
34.94
27656-9X
-
-2X
28.34
9.53
660118-1
-
18.81
27656-10X
-
28381
USES U-JOINT KIT 5-760X
B = 1.16 - 27
D = 1.31 - 30
-1X
23.50
8.72
36859
36364
14.78
27902-13X
-
-2X
41.62
8.72
36859
36364
32.91
27902-14X
-
-3X
26.86
8.72
36859
36364
18.14
27902-23X
-
-4X
44.36
8.72
36859
36364
35.64
27902-24X
-
