YOKE SHAFTS
For Independent Rear Suspensions (Corvette & Viper)
Dimensions & Components
XGI
Listed By Assembly Number
Note: Optional premium U-Joint Kits 1350 Series:
5-800X Aluminum yoke - non-greasable
5-799X Steel Yoke - non-greasable
Complete
Shaft Assy.
Part Number
Series
Use with
U-Joint Kit
Centerline
to End of
Spline
A
Spline Dia. &
Number of
Teeth
B
Flinger
Number
Yoke Shaft
Part
Number
-
6.70
1.177 - 27
3-82-1001-1
-
1350
5-447X
-
7.23
1.177 - 27
3-82-1001-2
-
1350
5-447X
-
7.27
1.177 - 27
41533-1
-
1350
5-447X
-
6.74
1.177 - 27
41533-2
-
1350
5-447X
-
6.74
1.177 - 27
46822-2
-
1350
5-447X
-
7.27
1.177 - 27
46822-1
-
1350
5-447X
70987-1X
6.57
1.310 - 30
2-82-1491-1
39591
1330
5-213X
70987-2X
7.42
1.310 - 30
2-82-1491-2
39591
1330
5-213X
71090-1X
6.57
1.310 - 30
3-82-961-1
39591
1350
5-178X
71090-2X
7.42
1.310 - 30
3-82-961-2
39591
1350
5-178X
72404-1X
7.36
1.310 - 30
41216-1
41218
1350
5-447X
72404-2X
6.59
1.310 - 30
41216-2
41218
1350
5-447X
74788-1X
7.36
1.310 - 30
45628-1
41218
1350
5-447X
74788-2X
6.59
1.310 - 30
45628-2
41218
1350
5-447X
