FRONT AXLE SHAFTS
Dimensions & Components
XGI
77
Axle Shaft Assy Outer Shaft Spindle End Inner Shaft Side Gear
Complete Overall Yoke Shaft Yoke Shaft
Assembly Length Part Slinger Part Slinger
Number Number Number
Length Length
A C E
909033 USES U-JOINT KIT 5-282X B = 1.25 - 19 D = 1.31 - 30
-1 30.33 11.30 3-82-841 36364 19.01 660179-1 -
-2 44.70 11.30 3-82-841 36364 33.20 660179-2 -
909218 USES U-JOINT KIT 5-806X/SPL55-3X B = 1.50 - 35 D = 1.50 - 35
-1 27.96 12.00 3-82-871 37308 15.96 660182-1 -
-2 47.20 12.00 3-82-871 37308 35.20 660182-2 -
-7 29.67 12.00 3-82-871 37308 17.67 660182-5 -
-8 47.07 12.00 3-82-871 37308 35.07 660182-6 -
-11 30.68 12.00 3-82-871 37308 18.68 660182-11 -
-15 46.56 12.00 3-82-871 37308 34.56 660182-10 -
