FRONT AXLE SHAFTS
Dimensions & Components
XGI
76
Listed By Complete Assembly Number
Axle Shaft Assy
Outer Shaft Spindle End
Inner Shaft Side Gear
Complete
Overall
Yoke Shaft
Yoke Shaft
Assembly
Length
Part
Slinger
Part
Slinger
Number
Number
Number
Length
Length
A
C
E
904685
USES U-JOINT KIT 5-260X
B = 1.25 - 19
D = 1.31 - 30
-1
28.26
9.76
2-82-1171
35975
18.50
27553-7X
35168
-2
45.86
9.76
2-82-1171
35975
36.12
27553-8X
35168
904686
USES U-JOINT KIT 5-260X
B = 1.25 - 19
D = 1.31 - 30
-3
27.22
9.72
2-82-1121
35975
17.50
27648-3X
35168
-4
44.84
9.72
2-82-1121
35975
35.12
27648-4X
35168
-5
43.62
9.72
2-82-1121
35975
33.96
27553-1X
35168
-6
28.62
9.72
2-82-1121
35975
18.91
27553-2X
35168
-7
28.03
9.72
2-82-1121
35975
18.31
27553-5X
35168
-9
37.66
9.72
2-82-1121
35975
27.94
27553-11X
35168
905192
USES U-JOINT KIT 5-260X
B = 1.16 - 27
D = 1.16 - 27
-1
23.62
8.72
2-82-1371
35975
14.91
27941-1X
35168
-2
41.75
8.72
2-82-1371
35975
33.03
27941-2X
35168
-5
22.86
8.72
2-82-1371
35975
14.14
27941-3X
35168
-6
35.73
8.72
2-82-1371
35975
27.01
2-82-1381-6
35168
905298
USES U-JOINT KIT 5-74X
B = 1.06 - 27
D = 1.16 - 27
-1
40.75
8.22
2-82-1391
37308
32.53
27658-1X
-
-2
24.12
8.22
2-82-1391
37308
15.91
27658-2X
-
907396
USES U-JOINT KIT 5-86X
B = 1.25 - 19
D = 1.31 - 30
-1
43.94
10.06
3-82-411
-
33.87
660183-1
-
-2
29.56
10.06
3-82-411
-
19.50
660183-2
-
907967
USES U-JOINT KIT 5-806X/SPL55-3X
B = 1.31 - 30
D = 1.50 - 35
-1
27.97
12.00
40955
37308
15.97
660182-1
-
-2
47.20
12.00
40955
37308
35.20
660182-2
-
-3
33.16
12.00
40955
37308
21.16
660182-3
-
-4
56.53
12.00
40955
37308
44.53
660182-4
-
-5
29.67
12.00
40955
37308
17.67
660182-5
-
-6
47.07
12.00
40955
37308
35.07
660182-6
-
-11
28.94
12.00
40955
37308
16.94
660182-34
-
-12
26.44
12.00
40955
37308
14.44
660182-12
-
-16
44.06
12.00
40955
37308
32.06
660182-26
-
-18
36.72
12.00
40955
37308
24.72
660182-30
-
-21
46.56
12.00
40955
37308
34.56
660182-10
-
-22
29.25
12.00
40955
37308
17.25
660182-21
-
-23
47.50
12.00
40955
37308
35.50
660182-22
-
