REAR AXLE SHAFTS
Dimensions & Components
XGI
81
Length of
Flange Face to
End of Shaft
D
Bolt Circle
Number of
Bolts
Float
Complete
Shaft Assy.
Part Number
Spline Dia. &
Number of
Teeth
A
Flange
Diameter
C
Spline
Length
B
35.01
33318-1
1.50 - 23
1.62
5.19
4.38
6
FULL
35.05
34414-1
1.50 - 23
1.62
4.75
3.97
8
FULL
35.05
35468-1
1.50 - 23
1.62
4.75
3.96
8
FULL
35.05
36113-1
1.50 - 35
1.62
4.75
3.96
8
FULL
35.44
41100-6
1.50 - 35
1.63
4.47
3.56
8
FULL
35.64
35953-3
1.31 - 30
1.81
4.75
3.96
8
FULL
35.76
35091-11
1.50 - 35
1.62
4.74
3.96
8
FULL
35.78
32987-1
1.31 - 30
1.81
4.75
4.00
6
FULL
35.81
31494-10
1.31 - 30
1.81
4.50
3.72
8
FULL
35.83
39260-3
1.31 - 30
1.81
4.75
3.96
8
FULL
35.91
35103-1
1.50 - 35
1.62
5.25
4.37
6
FULL
36.07
36113-22
1.50 - 35
1.62
4.75
3.96
8
FULL
36.09
35091-1
1.50 - 35
1.62
4.74
3.96
8
FULL
36.17
44264-1
1.58 - 37
1.74
3.90
—
-
FULL
36.18
36625-1
1.50 - 35
1.77
3.90
—
-
FULL
36.19
47037-1
1.58 - 37
1.74
5.12
4.25
8
FULL
36.20
36166-1
1.50 - 35
1.62
4.75
3.97
8
FULL
36.49
37560-4
1.31 - 30
1.81
4.75
3.96
8
FULL
36.49
41100-7
1.50 - 35
1.63
4.47
3.56
8
FULL
36.50
45553-3
1.50 - 35
1.74
4.74
3.96
8
FULL
36.65
45553-1
1.50 - 35
1.74
4.74
3.96
8
FULL
36.71
43811-12
1.37 - 32
1.62
4.72
3.96
8
FULL
36.76
43965-4
1.31 - 30
1.81
4.73
3.96
8
FULL
36.80
35953-2
1.31 - 30
1.81
4.75
3.96
8
FULL
36.85
37560-2
1.31 - 30
1.81
4.75
3.96
8
FULL
36.93
43811-3
1.37 - 32
1.62
4.72
3.96
8
FULL
36.94
35091-4
1.50 - 35
1.62
4.74
3.96
8
FULL
37.10
32987-3
1.31 - 30
1.81
4.75
4.00
6
FULL
37.22
35953-6
1.31 - 30
1.81
4.75
3.96
8
FULL
37.22
38378-4
1.31 - 30
1.81
4.74
3.96
8
FULL
37.22
39260-5
1.31 - 30
1.81
4.75
3.96
8
FULL
37.22
43965-3
1.31 - 30
1.81
4.73
3.96
8
FULL
37.31
35091-28
1.50 - 35
1.62
4.74
3.96
8
FULL
37.38
47847-3
1.50 - 35
1.62
4.88
4.02
8
FULL
37.40
36113-27
1.50 - 35
1.62
4.75
3.96
8
FULL
37.40
43811-4
1.37 - 32
1.62
4.72
3.96
8
FULL
37.42
36113-5
1.50 - 35
1.62
4.75
3.96
8
FULL
37.47
34887-5
1.31 - 30
1.81
4.75
3.96
8
FULL
37.47
36113-8
1.50 - 35
1.62
4.75
3.96
8
FULL
37.64
43811-17
1.37 - 32
1.62
4.72
3.96
8
FULL
37.67
42442-1
1.50 - 35
1.75
5.17
4.33
8
FULL
37.67
43286-1
1.50 - 35
1.75
5.17
4.33
8
FULL
37.67
43651-1
1.60 - 37
1.75
5.17
4.33
8
FULL
37.71
39260-8
1.31 - 30
1.81
4.75
3.96
8
FULL
37.83
35091-17
1.50 - 35
1.62
4.74
3.96
8
FULL
37.91
36113-18
1.50 - 35
1.62
4.75
3.96
8
FULL
38.64
35091-9
1.50 - 35
1.62
4.74
3.96
8
FULL
38.64
35953-1
1.31 - 30
1.81
4.75
3.96
8
FULL
38.67
43286-2
1.50 – 35
1.75
5.17
4.33
8
FULL
38.67
43651-2
1.58 – 37
1.75
5.17
4.33
8
FULL
