Ohaus CKW WASHDOWN CHECKWEIGHING SCALES_INDICATOR Manual en - Manual (Page 55)

CKW-55 CHECKWEIGHER EN-51
6. ACCESSORIES AND OPTIONS
DESCRIPTION PART NUMBER
Wall/Table Mount Kit 71167964
Column Mount Kit 71167972
RS232 Cable/Printer SF42 80500574
RS232 Cable/PC 25-pin 80500553
RS232 Cable/PC 9-pin 80500552
SF42 Printer SF42
External Foot Switch 71173378
Rechargeable Battery Kit 71167966
Replacement NiMH Battery 71172942
RS422/485 Interface Kit 71167965
AC Relay Kit 71167967
DC Relay Kit 71173377
6.1 Available Options
6.1.1 Relay Option
When installed, the Relay option board is detected by the software. During the display sequence the message REL OPT is
displayed to confirm the detection of this option.
For more information refer to the instruction manual included with the Option Kit when purchased.
6. 1.2 RS485/422 Option
When installed, the RS485/422 option board is detected by the software. During the power on display sequence the message
485 OP is displayed to confirm the detection of this option.
For more information refer to the instruction manual included in the Option Kit when purchased.
6.1.3 Rechargeable Battery Option
When installed, the Rechargeable Battery Option board is detected by the main board software. During the power display
sequence, the message BAT OP is displayed to confirm the detection of this option.
For more information refer to the instruction manual included in the Option Kit when purchased.
TABLE 6-1. ACCESSORIES AND OPTIONS.
