CKW-55 CHECKWEIGHER EN-23
Entering and Editing Library Data (Cont.)
or
To enter letters instead of numbers, use the ASCII entry format: Enter a 3 digit ASCII code
shown in Table 6-2, then press NEXT+/- button. The 3 digits convert to an equivalent single
ASCII character, non-displayable ASCII codes produce “_”. (Example: HAM-6 = 072, NEXT +/-,
065, NEXT +/-, 077, NEXT +/-,109, NEXT +/-, 045, NEXT +/-, 6.)
Note: two entries are required to make the letter M or W. (Use upper case followed by the
lower case ASCII code value).
Press LIBRARY Save and advance to the next parameter: Pre-set Tare. P-TARE momentarily
flashes.
Display flashes 0.000 or the last value entered. Use the numeric keys to enter the desired Pre-
set Tare value (example 0.500 kg).
In the following example, Variance has been selected as the Set Point Input in the Mode menu.
Press LIBRARY
Save to save the current entry and advance to the next parameter:
TARGET momentarily flashes.
Notes: 1. - - - - - - is displayed if no previous data was specified for the respective
parameters.
2. Use the C button to clear previous data.
Enter the desired value (example 4 kg) using the numeric keys.
Press LIBRARY Save to save the current entry and advance to the next parameter: VAR UN
(Variance-Under).
Note Note Note Note Note: Variance values are absolute, no negative value allowed.
Enter the desired Minimum tolerance value (example 1 kg) using the numeric keys.
Press LIBRARY Save to accept the entry. The calculated value 3.000 (4 kg – 1 kg) will freeze
momentarily to confirm the entry.
Advance to the next parameter: VAR OV (Variance-Over). VAR OV flashes momentarily. The
last Green Bar Graph and the first Red segment are displayed during entry.
Enter the desired Maximum tolerance value (example 1.5 kg) using the numeric keys.
